| Camera |
|---|
| Image Sensor | 1/2.7" CMOS |
| Max. Resolution | 2688 (H) × 1520 (V) |
| ROM | 256 MB |
| RAM | 1 GB |
| Scanning System | Progressive |
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s |
| Min. Illumination | 0.003 lux@F1.0 (Color, 30 IRE); 0.0003 lux@F1.0 (B/W, 30 IRE); 0 lux (illuminator on) |
| S/N Ratio | >56 dB |
| Illumination Distance | 30 m (IR) / 30 m (warm light) |
| Illuminator On/Off Control | Auto / Manual |
| Illuminator Number | 2 (IR LED); 2 (warm light) |
| Pan/Tilt/Rotation Range | Pan: 0°–360° / Tilt: 0°–90° / Rotation: 0°–360° |
| Lens |
|---|
| Lens Type | Fixed-focal |
| Mount Type | M12 |
| Focal Length | 2.8 mm; 3.6 mm |
| Max. Aperture | F1.0 |
| Field of View | 2.8 mm: Horizontal: 101°; Vertical: 53°; Diagonal: 120° / 3.6 mm: Horizontal: 82°; Vertical: 44°; Diagonal: 96° |
| Iris Type | Fixed |
| Close Focus Distance | 2.8 mm: 1.5 m / 3.6 mm: 2.2 m |
| DORI Distance |
| Lens | Detect | Observe | Recognize | Identify |
|---|
| 2.8 mm | 66.0 m | 26.4 m | 13.2 m | 6.6 m |
| 3.6 mm | 78.0 m | 31.2 m | 15.6 m | 7.8 m |
|
| Intelligence |
|---|
| IVS (Perimeter Protection) | Intrusion, tripwire (support the classification and accurate detection of vehicle and human) |
| SMD | SMD 4.0 |
| Intelligent Search | Work together with Smart NVR to perform intelligent search, event extraction and merging to event videos |
| AcuPick | Accurately match and quickly search targets (people and vehicles) with deep learning algorithms |
| AI SSA | Deep learning algorithms that adjust image parameters to the environment |
| Video |
|---|
| Video Compression | H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream) |
| Smart Codec | Smart H.265+; Smart H.264+ |
| AI Coding | AI H.265 (≥25% compression); AI H.264 (≥25% compression) |
| Video Frame Rate | Main stream: 2688 × 1520@(1–25/30 fps); Sub stream: 704 × 576@(1–25 fps)/704 × 480@(1–30 fps); Third stream: 1920 × 1080@(1–25/30 fps) |
| Stream Capability | 3 streams |
| Resolution | 4M; 3M; 1080p; 1.3M; 720p; D1; VGA; CIF |
| Bit Rate Control | VBR; CBR; ABR |
| Video Bit Rate | H.264: 3 kbps–16384 kbps / H.265: 3 kbps–16384 kbps |
| Day/Night | Auto (ICR) / Color / B/W |
| BLC | Yes |
| HLC | Yes |
| WDR | 120 dB |
| SSA | Yes |
| White Balance | Auto; natural; street lamp; outdoor; manual; regional custom |
| Gain Control | Auto / Manual |
| Noise Reduction | 3D NR |
| Motion Detection | OFF/ON (4 areas, rectangle) |
| Region of Interest (RoI) | Yes (4 areas) |
| Smart Illumination | Yes |
| Defog | Yes |
| Image Rotation | 0°/90°/180°/270° (supports 2688 × 1520 resolution and lower) |
| Mirror | Yes |
| Privacy Masking | 4 areas |
| LDC | Yes |
| Audio |
|---|
| Built-in MIC | Yes, dual MIC |
| Built-in Speaker | Yes |
| Audio Compression | PCM; G.711a; G.711Mu; G.726; G.723 |
| Alarm |
|---|
| Alarm Event | No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; scene changing; audio detection; etc. |
| Network |
|---|
| Network Port | RJ-45 (10/100 Base-T) |
| SDK and API | Yes |
| Protocol | IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; SNMP; P2P |
| Interoperability | ONVIF (Profile S; Profile G; Profile T); CGI |
| User/Host | 20 (Total bandwidth: 64 M) |
| Storage | FTP; SFTP; Micro SD card (support max. 512 GB); NAS |
| Browser | IE11; Chrome; Firefox |
| Management Software | Smart PSS Lite; DSS; DMSS |
| Mobile Phone | iOS; Android |
| Cyber Security | Video encryption; firmware encryption; configuration encryption; WSSE; IP/MAC filtering; X.509 certificate; syslog; HTTPS; 802.1x; trusted boot; etc. |
| Certification |
|---|
| Certification | CE-LVD: EN 62368-1; CE-EMC: EMC Directive 2014/30/EU |
| Port |
|---|
| Audio Input | 1 channel (RCA) |
| Audio Output | 1 channel (RCA) |
| Alarm Input | 1 channel: 5 mA 3–5 VDC (wet contact) |
| Alarm Output | 1 channel: 300 mA 12 VDC (wet contact) |
| Power |
|---|
| Power Supply | 12 VDC/PoE (802.3af) |
| Power Consumption | Basic: 3.7 W (12 VDC); 4.8 W (PoE) / Max.: 8.8 W (PoE) |
| Environment |
|---|
| Operating Temperature | –40 °C to +60 °C |
| Operating Humidity | ≤95% (non-condensing) |
| Ingress Protection | IP67 |
| Storage Temperature | –40 °C to +60 °C |
| Storage Humidity | ≤95% (non-condensing) |
| Structure |
|---|
| Casing | Metal + plastic |
| Dimensions | 288.4 mm × 94.4 mm × 84.7 mm (L × W × H) |
| Net Weight | 1.0 kg |
| Gross Weight | 1.23 kg |
