| Camera |
| Image Sensor |
1/2.7" CMOS |
| Max. Resolution |
2960 (H) × 1668 (V) |
| ROM |
4 GB |
| RAM |
1 GB |
| Scanning System |
Progressive |
| Electronic Shutter Speed |
Auto/Manual 1/3 s – 1/100,000 s |
| Min. Illumination |
0.0009 Lux@F1.6 (Color, 30 IRE); 0.0005 Lux@F1.6 (B/W, 30 IRE); 0 lux (Illuminator on) |
| S/N Ratio |
>56 dB |
| Illumination Distance |
Up to 80 m (262.47 ft) (IR) |
| Illuminator On/Off Control |
Auto; Manual |
| Illuminator Number |
4 (IR LED) |
| Angle Adjustment |
Pan: 0°–360°; Tilt: 0°–90°; Rotation: 0°–360° |
| Lens |
| Lens Type |
Fixed-focal |
| Lens Mount |
M12 |
| Focal Length |
2.8 mm; 3.6 mm; 6 mm; 8 mm |
| Max. Aperture |
F1.6 |
| Field of View |
2.8 mm: H: 111°; V: 58°; D: 132°; 3.6 mm: H: 92°; V: 45°; D: 110°; 6 mm: H: 57°; V: 30°; D: 65°; 8 mm: H: 43°; V: 24°; D: 48° |
| Iris Control |
Fixed |
| Close Focus Distance |
2.8 mm: 1.1 m (3.06 ft); 3.6 mm: 1.7 m (5.58 ft); 6 mm: 3.2 m (10.50 ft); 8 mm: 4.6 m (15.09 ft) |
| DORI Distance |
| Lens | Detect | Observe | Recognize | Identify |
|---|
| 2.8 mm | 63.6 m (208.66 ft) | 25.4 m (83.33 ft) | 12.7 m (41.67 ft) | 6.4 m (21.00 ft) |
| 3.6 mm | 85.4 m (280.18 ft) | 34.2 m (112.20 ft) | 17.1 m (56.10 ft) | 8.5 m (27.89 ft) |
| 6 mm | 124.0 m (406.82 ft) | 49.6 m (162.73 ft) | 24.8 m (81.36 ft) | 12.4 m (40.68 ft) |
| 8 mm | 150.4 m (493.44 ft) | 60.2 m (197.51 ft) | 30.1 m (98.75 ft) | 15.0 m (49.21 ft) |
|
| DORI Note |
DORI (Detect, Observe, Recognize, Identify) is a standard system (EN 62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to the installation and commissioning manual/project design tool. |
| Intelligence |
| IVS (Perimeter Protection) |
Intrusion, tripwire, fast moving (the three functions support the classification and accurate detection of vehicle, animal and human); loitering detection, people gathering, parking detection. Supports long-distance mode. Supports self-learning; it filters out false alarms. |
| Smart Object Detection |
Smart abandoned object; smart missing object |
| SMD |
SMD 3.0 |
| AcuPick |
Uses deep learning algorithms and works with back-end devices to accurately match targets such as people, animals and motor vehicles, and searches through live and recorded videos to quickly locate targets. |
| AI SSA |
Yes |
| Face Detection |
Face detection; track; snapshot; snapshot optimization; optimal face snapshot upload; face enhancement; face exposure; face attributes extraction including 6 attributes and 8 expressions; face snapshot set as face, one-inch photo or custom; snapshot strategies (real-time snapshot, quality priority and optimization snapshot); face angle filter; optimization time setting |
| People Counting |
Tripwire people counting, generating and exporting report (day/week/month/year); people counting in area and queue management, generating and exporting report (day/week/month); 4 rules can be set for tripwire, people counting in area and queue management. |
| Heat Map |
Yes |
| Video Metadata |
Motor vehicle, non-motor vehicle, face, human body detection; track; snapshot; snapshot optimization; optimal face snapshot upload. Motor vehicle attributes: vehicle type, vehicle color, vehicle logo and other attributes (seatbelt, smoking, calling). Non-motor vehicle attributes: type, color, number of people, top type and color, hat. Human body attributes: gender, top/bottom type and color, bag, hat and umbrella. Face attributes: gender, age, expressions, glasses, face mask and beard. |
| Smart Search |
Works together with Smart NVR to perform refined intelligent search, event extraction and merging into event videos. |
| Smart Sound Detection |
Yes |
| Video |
| Video Compression |
H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream) |
| Smart Codec |
Smart H.265+; Smart H.264+ |
| AI Coding |
AI H.265; AI H.264 |
| Video Frame Rate |
Main stream: 2960 × 1668@(1–25/30 fps); Sub stream: D1@(1–25/30 fps); Third stream: 1080p@(1–25/30 fps); Fourth stream: 720p@(1–25/30 fps). The values above are the max. frame rates of each stream; for multiple streams, the values will be subject to the total encoding capacity. |
| Stream Capability |
4 streams |
| Resolution |
5M (2960 × 1668/2880 × 1620); 4M (2688 × 1520); 3.6M (2560 × 1440); 3M (2048 × 1536/2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) |
| Bit Rate Control |
CBR/VBR |
| Video Bit Rate |
H.264: 32 kbps – 16384 kbps; H.265: 12 kbps – 11776 kbps |
| Day/Night |
Auto (ICR)/Color/B/W |
| BLC |
Yes |
| HLC |
Yes |
| WDR |
120 dB |
| Scene Self-adaptation (SSA) |
Yes |
| White Balance |
Auto; natural; street lamp; outdoor; manual; regional custom |
| Gain Control |
Auto |
| Noise Reduction |
3D NR |
| Motion Detection |
OFF/ON (4 areas, rectangular) |
| Region of Interest (RoI) |
Yes (4 areas) |
| Smart Illumination |
Yes |
| Defog |
Yes |
| Image Rotation |
0°/90°/180°/270° (support 90°/270° with 4M (2688 × 1520) resolution and lower) |
| Mirror |
Yes |
| Privacy Masking |
8 areas |
| LDC |
Yes (only 2.8 mm/3.6 mm supports) |
| Audio |
| Built-in MIC |
Yes |
| Audio Compression |
G.711a; G.711Mu; PCM; G.726; G.723 |
| Alarm |
| Alarm Event |
No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; fast moving; abandoned object; missing object; loitering detection; people gathering; parking detection; scene changing; audio detection; voltage detection; external alarm; face detection; video metadata; SMD; people counting in area; stay detection; people counting; people number error detection; queue people number alarm; queue time alarm; security exception |
| Network |
| Network Port |
RJ-45 (10/100 Enhanced Base-T) |
| SDK and API |
Yes |
| Network Protocol |
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP; P2P; Auto Register |
| Interoperability |
ONVIF (Profile S/Profile G/Profile T/Profile M); CGI |
| User/Host |
20 (Total bandwidth: 80 M) |
| Storage |
FTP; SFTP; Micro SD card (support max. 1 TB); NAS |
| Browser |
IE: IE 9 and later; Chrome: Chrome 102 and later; Firefox: Firefox 88 and later |
| Management Software |
SmartPSS Lite; DSS; DMSS |
| Mobile Client |
iOS; Android |
| Cyber Security |
Configuration encryption; trusted execution; Digest; security logs; WSSE; account lockout; syslog; video encryption; 802.1x; IP/MAC filtering; HTTPS; trusted upgrade; trusted boot; firmware encryption; generation and importing of X.509 certification |
| Certification |
| Certifications |
CE-LVD: EN 62368-1; CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU; FCC: 47 CFR FCC Part 15, Subpart B; UL/CUL: UL 62368-1 & CAN/CSA C22.2 No. 62368-1-14 |
| Port |
| Audio Input |
1 channel (RCA port) |
| Audio Output |
1 channel (RCA port) |
| Alarm Input |
1 channel in: wet contact, 5 mA, 3 V – 5 VDC |
| Alarm Output |
1 channel out: wet contact, 300 mA, 12 V DC |
| Power |
| Power Supply |
12 VDC/PoE (802.3af)/ePoE |
| Dual Power Backup |
When the power adapter and PoE provide power at the same time and one of them is disconnected, the device will continue to work but will not restart. |
| Power Consumption |
Basic: 4.1 W (12 VDC); 5.2 W (PoE). Max. (H.265+ WDR+ Intelligence on+ IR on): 8.3 W (12 VDC); 9.8 W (PoE) |
| Environment |
| Operating Temperature |
–40 °C to +60 °C (–40 °F to +140 °F) |
| Operating Humidity |
≤95% |
| Storage Temperature |
–40 °C to +60 °C (–40 °F to +140 °F) |
| Storage Humidity |
10% – 95% (RH), non-condensing |
| Protection |
IP67; IK10 |
| Structure |
| Casing Material |
Metal |
| Product Dimensions |
244.1 mm × 79.0 mm × 75.9 mm (9.61" × 3.11" × 2.99") (L × W × H) |
| Net Weight |
0.82 kg (1.81 lb) |
| Gross Weight |
1.08 kg (2.38 lb) |
