Carries 5MP video and room audio over a single coaxial run and lights the scene up to 30 m in the dark.

An eyeball-body HDCVI camera with a built-in microphone for indoor surveillance. The 1/2.7 inch CMOS sensor delivers 2880 × 1620 video at 25 fps, and a single BNC port switches between CVI, TVI, AHD and CVBS output. The fixed-focal 3.6 mm lens ships as standard and a 2.8 mm lens remains available as an option.

5MPResolution

2880 × 1620Max. Resolution

2.8 mm / 3.6 mmFocal Length

F1.6Maximum Aperture

30 mIR LED Distance

IP67Protection Grade

Key features

5MP

High definition surveillance

The sensor delivers 2880 × 1620 pixels and holds detail across the scene.

25fps

Smooth motion

The camera streams 25 frames per second at full resolution.

30m

Smart IR night view

Smart IR cuts glare on close objects and lights the scene evenly.

1channel

Audio from the built-in mic

The camera sends room audio to the recorder alongside the video.

0.005Lux

Color in low light

The F1.6 aperture keeps color information in dim rooms.

IP67rating

Sealed against dust and water

A metal dome and metal cover shield the camera from the elements.

IN DAILY USE

Fast mountingThe eyeball body sets the viewing angle in one move and shortens installation time.

Video and format choice on one cableOne BNC connection ties the camera into an existing analog recording setup.

Wide temperature rangeThe camera operates from –40 °C to +60 °C.

Camera

Image Sensor

1/2.7 inch CMOS

Max. Resolution

2880 (H) × 1620 (V)

Effective Pixels

5MP

Scanning System

Progressive

Electronic Shutter Speed

PAL: 1/25 s–1/100,000 s
NTSC: 1/30 s–1/100,000 s

S/N Ratio

> 65 dB

Min. Illumination

0.005 Lux/F1.6, 30IRE, 0 Lux IR on

IR Distance

30 m (98.4 ft)

Illumination On/Off Control

Auto; manual

Illuminator Number

Pan/Tilt/Rotation Range

Pan: 0°–360°
Tilt: 0°–78°
Rotation: 0°–360°

Lens

Lens Type

Fixed-focal

Mount Type

M12

Focal Length

2.8 mm; 3.6 mm

Max. Aperture

F1.6

Field of View

2.8 mm: 132° × 111° × 58° (diagonal × horizontal × vertical)
3.6 mm: 109° × 92° × 48° (diagonal × horizontal × vertical)

Iris Type

Fixed iris

Close Focus Distance

2.8 mm: 0.9 m (3.0 ft)
3.6 mm: 1.6 m (5.2 ft)

DORI Distance

Lens	Detect	Observe	Recognize	Identify
2.8 mm	63.6 m (208.7 ft)	25.4 m (83.3 ft)	12.7 m (41.7 ft)	6.4 m (21.0 ft)
3.6 mm	80 m (262.5 ft)	32 m (105.0 ft)	16 m (52.5 ft)	8 m (26.2 ft)

Video

Frame Rate

CVI:
PAL: 5M@25 fps; 4M@25 fps; 1080P@25 fps;
NTSC: 5M@25 fps; 4M@30 fps; 1080P@30 fps
AHD:
PAL: 4M@25 fps;
NTSC: 4M@30 fps
TVI:
PAL: 4M@25 fps;
NTSC: 4M@30 fps
CVBS:
PAL: 960H;
NTSC: 960H

Resolution

5M (2880 × 1620); 4M (2560 × 1440); 1080P (1920 × 1080); 960H (960 × 576/960 × 480)

Day/Night

Auto switch by ICR

BLC

BLC/HLC/DWDR

WDR

DWDR

White Balance

Auto; manual

Gain Control

Auto; manual

Noise Reduction

2D NR

Smart IR

Yes

Mirror

Off/On

Privacy Masking

Off/On (8 areas, rectangle)

Certifications

CE (EN55032:2015, EN 61000-3-2:2014, EN 61000-3-3:2013, EN55024:2010+A1:2015, EN 55035:2017, EN50130-4:2011+A1:2014, EN 62368-1:2014+A11:2017)
FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
UL (UL60950-1+CAN/CSA C22.2 No.60950-1)

Port

Audio Interface

One channel built-in mic (-A)

Video Output

Video output choices of CVI/TVI/AHD/CVBS by one BNC port

Power

Power Supply

12V ±30% DC

Power Consumption

Max. 3.2W (12V DC, IR on)

Environment

Operating Temperature

–40°C to +60°C (–40°F to 140°F); < 95% (non-condensation)

Storage Temperature

–40°C to +60°C (–40°F to 140°F); < 95% (non-condensation)

Protection Grade

IP67

Structure

Casing

Metal dome + metal cover + plastic decorative ring

Dimensions

φ109.9 mm × 88.1 mm (φ4.33" × 3.47")

Net Weight

0.33 kg (0.73 lb)

Gross Weight

0.44 kg (0.97 lb)
