Stock Code: SD49825GB-HNR
| Camera | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Image Sensor | 1/2.8" CMOS | ||||||||
| Pixel | 8 MP | ||||||||
| Max. Resolution | 3840 (H) × 2160 (V) | ||||||||
| ROM | 4 GB | ||||||||
| RAM | 1 GB | ||||||||
| Electronic Shutter Speed | 1/1 s – 1/30,000 s | ||||||||
| Scanning System | Progressive | ||||||||
| Min. Illumination | Color: 0.005 lux@F1.6 B/W: 0.0005 lux@F1.6 0 lux@F1.6 (IR light on) |
||||||||
| Illumination Distance | 100 m (328.08 ft) (IR) | ||||||||
| Illuminator On/Off Control | Zoom Prio; Manual; Smart IR; Off | ||||||||
| Illuminator Number | 4 (IR) | ||||||||
| Lens | |||||||||
| Focal Length | 5 mm – 125 mm | ||||||||
| Max. Aperture | F1.6 – F3.6 | ||||||||
| Field of View | H: 53.1° – 3.4° V: 30.4° – 1.9° D: 59.3° – 3.9° |
||||||||
| Optical Zoom | 25× | ||||||||
| Focus Control | Auto; semi-auto; manual | ||||||||
| Close Focus Distance | 0.1 m – 1.5 m (0.33 ft – 4.92 ft) | ||||||||
| Iris Control | Auto; manual | ||||||||
| DORI Distance | |||||||||
| DORI Distance |
|
||||||||
| PTZ | |||||||||
| Pan/Tilt Range | Pan: 0° to 360° endless Tilt: –15° to +90°, auto flip 180° |
||||||||
| Manual Control Speed | Pan: 0.1°/s – 200°/s Tilt: 0.1°/s – 120°/s |
||||||||
| Preset Speed | Pan: 240°/s Tilt: 200°/s |
||||||||
| Preset | 300 | ||||||||
| Tour | 8 (up to 32 presets per tour) | ||||||||
| Pattern | 5 | ||||||||
| Scan | 5 | ||||||||
| Power-off Memory | Yes | ||||||||
| Idle Motion | Pattern; Preset; Scan; Tour | ||||||||
| PTZ Protocol | DH-SD; Pelco-P/D (Auto recognition) | ||||||||
| Intelligence | |||||||||
| IVS (Perimeter Protection) | Tripwire; intrusion; crossing fence detection; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; vehicle/human alarm classification | ||||||||
| Face Detection | Supports face detection, optimization, tracking, capturing pictures, uploading high-quality face snapshots, and face enhancement; Supports attributes extraction. 6 attributes and 8 expressions: Gender, age, glasses, expressions (angry, sad, hate, scary, surprise, calm, happy and confused), mask, mustache; Supports face cutout: Face, one-inch photo. Capturing strategies include real-time capturing, optimization, and quality first. Supports up to 5 face databases; registers person one by one or in batches; sets face similarity; compares faces with 10,000 faces | ||||||||
| SMD | Yes | ||||||||
| Quick Pick | Yes | ||||||||
| Video | |||||||||
| Video Compression | H.264H; H.264B; Smart H.265+; H.264; H.265; MJPEG (Sub Stream); Smart H.264+ | ||||||||
| Streaming Capability | 3 streams | ||||||||
| Resolution | 4K (3840 × 2160); 4M (2560 × 1440); 3M (2048 × 1536); 3M (2304 × 1296); 1080p (1920 × 1080); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) | ||||||||
| Video Frame Rate | Main stream: 4K/4M/1080p/1.3M/720p (1–25/30 fps) Sub stream 1: D1/VGA/CIF (1–25/30 fps) Sub stream 2: 1080p/1.3M/720p/CIF (1–25/30 fps) |
||||||||
| Bit Rate Control | CBR / VBR | ||||||||
| Video Bit Rate | H.264: 3,328 kbps – 8,192 kbps H.265: 1,280 kbps – 8,192 kbps |
||||||||
| Day/Night | Auto (ICR) / Color / B/W | ||||||||
| BLC | Yes | ||||||||
| WDR | Yes | ||||||||
| HLC | Yes | ||||||||
| White Balance | Auto; indoor; outdoor; ATW; manual; sodium lamp; natural light; street lamp | ||||||||
| Gain Control | Auto; manual | ||||||||
| Noise Reduction | 2D NR; 3D NR | ||||||||
| Motion Detection | Yes | ||||||||
| Region of Interest (RoI) | Yes | ||||||||
| Defog | Electronic | ||||||||
| Digital Zoom | 16× | ||||||||
| Image Rotation | 180° | ||||||||
| Privacy Masking | Up to 24 areas can be set, with up to 8 areas in the same view | ||||||||
| S/N Ratio | ≥ 55 dB | ||||||||
| Audio | |||||||||
| Audio Compression | PCM; G.711a; G.711Mu; G.726; MPEG2-Layer2; G722.1; G729; G723 | ||||||||
| Network | |||||||||
| Network Port | 1 × RJ-45 (10/100 Base-T) | ||||||||
| Network Protocol | FTP; RTMP; IPv6; Bonjour; IPv4; DNS; RTCP; PPPoE; NTP; RTP; 802.1x; HTTPS; SNMP; TCP/IP; DDNS; UPnP; NFS; ICMP; UDP; IGMP; HTTP; SSL; DHCP; SMTP; Qos; RTSP; ARP | ||||||||
| Interoperability | RTMP; CGI; SDK; ONVIF (Profile S&G&T); P2P | ||||||||
| Streaming Method | Unicast / Multicast | ||||||||
| User/Host | 20 (total bandwidth: 64 M) | ||||||||
| Storage | Micro SD card (512 GB); FTP/SFTP; NAS | ||||||||
| Browser | IE 9 and later versions; Chrome 41 and later versions; Firefox 50 and later versions; iOS 10 and later versions | ||||||||
| Management Software | DSS; DMSS | ||||||||
| Mobile Client | iOS; Android | ||||||||
| Certification | |||||||||
| Certifications | CE-EMC: EN 55032; EN 61000-3-3; EN 61000-3-2; EN 50130-4; EN 55035 CE-LVD: EN 62368-1 FCC: 47 CFR FCC Part15, Subpart B, ANSI C63.4 UL: UL62368-1 |
||||||||
| Port | |||||||||
| Audio Input | 1 channel | ||||||||
| Audio Output | 1 channel | ||||||||
| Alarm Linkage | Capture; recording; send email; preset; tour; pattern; alarm digital input | ||||||||
| Alarm Event | Motion/Tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection | ||||||||
| Alarm I/O | 2/1 | ||||||||
| Audio I/O | 1/1 | ||||||||
| Power | |||||||||
| Power Supply | 12 VDC/3A ± 10% PoE (802.3at) |
||||||||
| Power Consumption | Basic: 9.8 W Max.: 20 W (Illuminator + alarm + PTZ) |
||||||||
| Environment | |||||||||
| Operating Temperature | –40 °C to +65 °C (–40 °F to +149 °F) | ||||||||
| Operating Humidity | ≤ 95% | ||||||||
| Storage Temperature | –40 °C to +65 °C (–40 °F to +149 °F) | ||||||||
| Storage Humidity | ≤ 95% | ||||||||
| Protection | IP66; TVS 6000 V lightning proof; surge protection; voltage transient protection | ||||||||
| Structure | |||||||||
| Product Dimensions | 270.4 mm × Φ160 mm (10.65" × Φ6.30") | ||||||||
| Net Weight | 2.4 kg (5.29 lb) | ||||||||
| Gross Weight | 3.9 kg (8.60 lb) | ||||||||
