Stock Code: VTH1010J
| Display & Structural Features | |
|---|---|
| Display Type | 4.3" TFT Screen |
| Resolution | 480 (H) × 272 (V) |
| Button Type / Casing | Touch Button / ABS Plastic |
| Communication Mode | Analog |
| General Parameters | |
| Power Supply | 12 VDC 1 A (Power Adapter Included) |
| Power Consumption | Standby ≤ 2 W / Working ≤ 5 W |
| Installation | Surface Mount (Bracket Included) |
| Dimensions & Environment | |
| Product Dimensions | 136.00 mm × 140.00 mm × 18.30 mm |
| Weight | Net: 0.16 kg / Gross: 0.42 kg |
| Operating Conditions | –10 °C ~ +55 °C / 10%–95% RH |
