Stock Code: VTA8311AB
| Ports | |
|---|---|
| Alarm Input | 2 |
| Alarm Output | 2 |
| Network Port | 2 × RJ-45 10/100 Mbps self-adaptive Ethernet |
| Telephone Line | 1 × PSTN |
| SIM Card Slot | Yes (4G optional) |
| RS-232 | 1 |
| RS-485 | 1 (supports dot-matrix display) |
| Auxiliary Power Output | 1 × 12 V / 1 A |
| SD Card Slot | 1 × Micro SD (max. 256 GB) |
| Video & Audio | |
| Video Compression | H.264 / H.265 |
| Audio Input | 1 channel, 5 m pickup distance, supports external microphone |
| Audio Output | 1 channel, max. 30 W, supports active speaker |
| Audio Compression | G.711a / G.711U / PCM / G.726 / AAC |
| Volume Control | Yes |
| Two-way Audio | Yes |
| Field of View | D: 105° H: 88° V: 44° |
| Resolution | 704×480; 640×480; 1280×720; 1920×1080 |
| Frame Rate | 1–25 fps |
| Illumination Mode | IR illumination |
| Illumination Distance | 30 m |
| Day / Night | Yes |
| Functions | |
| Indicator Light | 2 pcs (alarm & alarm button) |
| Button | 1 × alarm button |
| External Accessory | Vertical pole |
| Phone Call | Yes |
| Video Linkage | Yes |
| OSD | Up to 5 lines, 60 characters per line via web interface |
| Arm / Disarm | Via web |
| Remote Update | Yes |
| FTP Server | Yes |
| Tamper Alarm | 2-channel door detector |
| Log Records | 10,000 records |
| General | |
| Language | English |
| Power Supply | 110–240 VAC |
| Power Consumption | Idle: 20 W Full load: 55 W |
| Operating Temperature | –30 °C ~ +65 °C |
| Operating Humidity | 93% @ +40 °C |
| Product Dimensions | 2410 × 340 × 330 mm |
| Package Dimensions | 2667 × 615 × 715 mm |
| Net Weight | 95 kg |
| Gross Weight | 110 kg |
| Installation | Cage footing mount |
| Casing Material | Galvanized steel sheet |
| Protection | IPX5 |
