Stock Code: VTA8311A-4
| Ports | |
|---|---|
| Alarm Input | 2 |
| Alarm Output | 2 |
| Network Port | 2 × RJ-45 10/100 Mbps self-adaptive Ethernet port |
| Telephone Line | 1 × PSTN |
| SIM Card Slot | Yes (4G optional) |
| RS-232 | 1 |
| RS-485 | 1 (supports accessing a dot-matrix display) |
| Auxiliary Power Output | 1 × 12 V / 1 A |
| Screen | 10.1" LCD – 1280 × 800 – 5.38 W – LVDS port |
| SD Card Slot | 1 × Micro SD card slot (max. 256 GB) |
| Video & Audio | |
| Video Compression | H.264 / H.265 |
| Audio Input | 1 channel, max 5.0 m pickup distance; supports external microphone |
| Audio Output | 1 channel, max 30 W; supports active speaker |
| Audio Compression | G.711a / G.711U / PCM / G.726 |
| Volume Control | Yes |
| Two-way Audio | Yes |
| Field of View | D: 105° H: 88° V: 44° |
| Image Type | Supports importing images in PNG, JPG, BMP for ads |
| Video Type | Supports importing videos in AVI, DAV, MP4 for ads |
| Resolution | 704 × 480; 640 × 480; 1280 × 720; 1920 × 1080 |
| Frame Rate | 1–25 fps |
| Illumination Mode | IR illumination |
| Illumination Range | 30 m (98.43 ft) |
| Day/Night | Yes |
| Functions | |
| Indicator Light | 2 indicators (alarm & alarm button) |
| Button | 1 × alarm button |
| External Accessories | Vertical pole |
| Phone Call | Yes |
| Video Linkage | Yes |
| OSD Overlay | Up to 5 lines, 60 characters per line on webpage |
| Arm / Disarm | On webpage |
| Remote Update | Yes |
| Network Protocol | DHCP; UPNP; NTP |
| FTP Server | Yes |
| Tamper | 2-channel door detector tamper alarm |
| Logs | Up to 10,000 logs (including alarm & operation logs) |
| Remote Alarm Event Search | Yes |
| General | |
| Language | English |
| Power Supply | 110–240 VAC |
| Power Consumption | Idling: 20 W (without speakers) Full load: 55 W |
| Operating Temperature | –30 °C ~ +65 °C (–22 °F ~ +149 °F) |
| Operating Humidity | 93% @ +40 °C (+104 °F) |
| Product Dimensions | 2,410 × 340 × 330 mm (94.88" × 13.38" × 12.99") |
| Packaging Dimensions | 2,667 × 615 × 715 mm (105.00" × 24.21" × 28.15") |
| Net Weight | 95 kg (209.44 lb) |
| Gross Weight | 110 kg (242.51 lb) |
| Installation | Footing cage mount |
| Casing Material | Galvanized plate |
| Protection | IPX5 |
