Stock Code: DHI-VTO7541G
| System | |
|---|---|
| Main Processor | Embedded processor |
| Internet Protocol | IPv4, FTP, DNS, RTSP, RTP, TCP, UDP, SIP |
| Keyboard Type | Touch keyboard |
| Basic | |
| Appearance | G series |
| Display | High definition IPS screen |
| Screen Type | Capacitive screen |
| Resolution | 800 (H) × 1280 (V) |
| Camera | 1/2.8" 2MP CMOS |
| Angle of View | H: 88°, V: 47°, D: 105° |
| WDR | 120 dB |
| Light Compensation | Auto white light fill light; Auto IR fill light |
| Status Indicator | 1, blue - operation status |
| Voice Prompt | Yes |
| Housing Material | AL+PC+ABS |
| Function | |
| Unlock Mode | Remote / password / face / fingerprint / card |
| Online Update | Yes |
| Full Duplex Communication | Yes |
| Snapshot When Unlocking Doors | Yes |
| Information Release | Words, pictures, and videos can be played on the outdoor station |
| Leave Photos and Messages | Yes |
| Web Configuration | Yes |
| Motion Detection | Video motion detection |
| Issue Card Locally | Yes |
| Auto-Registration | Yes |
| Performance | |
| Face Recognition Range | Face-camera distance: 0.3 m – 2.0 m; Human height: 1.1 m – 2.4 m |
| Face Recognition Configuration | Anti-fake switch; Recognition threshold; Facial profile angle |
| Face Verification Accuracy | >99% |
| Face Comparison Time | ≤0.2s |
| Capacity | |
| Face Capacity | 20,000 |
| Card Capacity | 10,000 |
| Fingerprint Capacity | 10,000 |
| Port | |
| RS-485 | 1 |
| Wiegand | 1 (input or output) |
| Ethernet | 1 × 10M/100M/1000M Ethernet port |
| Alarm Input | 2 (Switch quantity) |
| Alarm Output | 2 (Dry contact) |
| Alarm Linkage | Yes |
| Power Output | 1 × DC 12V/100mA |
| Exit Button | 1 |
| Door Status Detection | 1 |
| Lock Control | 1, normally on or off by default |
| Alarm | |
| Duress Alarm | Yes |
| Tamper Alarm | Yes |
| Door Sensor Timeout | Yes |
| General | |
| Ingress Protection | IP66 (Apply silica gel to gaps between the device and the wall. Liquid sodium silicate is recommended. For details, see the quick start guide.) |
| Power Supply | Optional |
| Power Supply Mode | DC 12V/2A |
| Power Consumption | ≤24.0W |
| Product Dimensions | 389mm × 145mm × 43mm (15.31" × 5.71" × 1.69") |
| Packaging Dimensions | 413mm × 182mm × 104mm (16.26" × 7.17" × 4.09") |
| Operating Temperature | -20°C to +60°C (-4°F to +140°F) |
| Operating Humidity | 10% RH – 90% RH |
| Operating Altitude | 86 kPa – 106 kPa |
| Gross Weight | 1.91kg (4.21 lb) |
| Accessory | Mount plate |
| Installation Method | Surface mount and flush mount |
| Operating Environment | Outdoor |
