Name: IP Villa Door Station
Brand: Dahua
SKU: VTO2101E-P-S2

Brings video calling and door control together on a single entrance panel.

The vandal-resistant zinc alloy door station shows the visitor through its 1/2.8" 2 MP HD CMOS camera and holds a two-way conversation with the indoor monitors. Its single mechanical button panel surface mounts at villa and detached building entrances.

1/2.8" 2 MPHD CMOS Camera

90°Field of View

H.265 / H.264Video Compression

IP65 · IK10Protection Grade

12 V DC / PoEPower Supply

Key features

Night and backlightAuto IR night vision switches on in darkness, while 120 dB WDR and 3D/2D noise reduction keep facial detail against strong backlight.

Vandal protectionIP65 sealing and IK10 impact rating keep the zinc alloy panel intact at unprotected entrances.

Network and protocolsSupports SIP, ONVIF, CGI, P2P and RTSP; the 10/100M RJ-45 port accepts standard PoE power.

Door controlLock control, exit button and alarm input ports manage the door, and the tamper alarm reports any interference with the panel.

Wide temperature rangeOperates from –40 °C to +60 °C and draws ≤ 2.5 W in standby, ≤ 5 W in operation.

VTO2101E-P-S2 Vandal-Proof IP Villa Door Station

Camera

1/2.8" 2MP HD CMOS

Field of View

H: 80°; V: 40°; D: 90°

Image Processing

120 dB WDR; 3D/2D Noise Reduction; Auto IR Night Vision

Casing Material

Zinc Alloy (Grey)

Button Type

Mechanical (Single Button)

Interoperability

SIP; ONVIF; CGI; P2P; RTSP

Video Compression

H.265 / H.264

Protection Rating

IP65 (Weatherproof); IK10 (Vandal-proof)

Power Supply

12 VDC, 1 A / Standard PoE

Operating Temperature

–40 °C to +60 °C

Dimensions

163.0 mm × 73.0 mm × 55.0 mm

Installation

Surface Mount

Power Consumption

Standby: ≤ 2.5 W / Working: ≤ 5 W

Certifications

CE; FCC

Interface & Connection Ports

I/O Ports

1 × RJ-45 (10/100M); 1 × RS-485; 1 × Alarm Input; 1 × Lock Control; 1 × Exit Button; Tamper Switch

Brings video calling and door control together on a single entrance panel.

1/2.8" 2 MPHD CMOS Camera

90°Field of View

H.265 / H.264Video Compression

IP65 · IK10Protection Grade

12 V DC / PoEPower Supply

Key features

Night and backlightAuto IR night vision switches on in darkness, while 120 dB WDR and 3D/2D noise reduction keep facial detail against strong backlight.

Vandal protectionIP65 sealing and IK10 impact rating keep the zinc alloy panel intact at unprotected entrances.

Network and protocolsSupports SIP, ONVIF, CGI, P2P and RTSP; the 10/100M RJ-45 port accepts standard PoE power.

Door controlLock control, exit button and alarm input ports manage the door, and the tamper alarm reports any interference with the panel.

Wide temperature rangeOperates from –40 °C to +60 °C and draws ≤ 2.5 W in standby, ≤ 5 W in operation.

VTO2101E-P-S2 Vandal-Proof IP Villa Door Station

Camera

1/2.8" 2MP HD CMOS

Field of View

H: 80°; V: 40°; D: 90°

Image Processing

120 dB WDR; 3D/2D Noise Reduction; Auto IR Night Vision

Casing Material

Zinc Alloy (Grey)

Button Type

Mechanical (Single Button)

Interoperability

SIP; ONVIF; CGI; P2P; RTSP

Video Compression

H.265 / H.264

Protection Rating

IP65 (Weatherproof); IK10 (Vandal-proof)

Power Supply

12 VDC, 1 A / Standard PoE

Operating Temperature

–40 °C to +60 °C

Dimensions

163.0 mm × 73.0 mm × 55.0 mm

Installation

Surface Mount

Power Consumption

Standby: ≤ 2.5 W / Working: ≤ 5 W

Certifications

CE; FCC

Interface & Connection Ports

I/O Ports

1 × RJ-45 (10/100M); 1 × RS-485; 1 × Alarm Input; 1 × Lock Control; 1 × Exit Button; Tamper Switch
