Isolator Module

Name: Isolator Module
Brand: Dahua
SKU: HY-1431

Stock Code: HY-1431

Isolates a short circuit on the line and keeps the rest of the loop running.

An isolator module for addressable fire detection loops. It separates the section where it detects a short circuit and confines the fault to a single zone.

24V DCWorking Voltage

≤ 8 mAAlarm current

≤ 150 µAMonitoring current

450 mAShort Circuit Current

≤ 1500 mCommunication Distance

90 × 90 × 37 mmDimensions

Key features

WiringIt uses a two-wire, polarity-free line, so installation needs no polarity check.

Short circuit protectionIt acts at a short circuit current of 450 mA and separates the faulty section from the loop.

IndicatorThe red LED flashes once every 6 seconds during polling, drops to 2 seconds on a fault and stays lit during a short circuit.

Operating conditionsIt works between -10°C and +55°C and up to 95% relative humidity.

CertificationIt meets the GB16806-2006 standard.

Electrical
Working Voltage	24V DC
Current	Monitoring current: ≤ 150µA Alarm current: ≤ 8mA
Short Circuit Current	450mA
Indicator	Red LED flashes once every 6 seconds during polling, flashes once every 2 seconds during malfunctioned, and remains lit during short circuit
Communication Wiring
Wiring	Two-wire, polarity-free
Communication Distance	≤ 1500 m
Environment
Operating Temperature	–10°C to +55°C (+14°F to +131°F)
Storage Temperature	–20°C to +65°C (–4°F to +149°F)
Operating Humidity	≤ 95% RH (no condensation)
Construction
Color	White
Dimensions (with base)	90 mm × 90 mm × 37 mm (3.54" × 3.54" × 1.46")
Weight (with base)	107 g (0.24 lb)
General
Certification	GB16806-2006
Certification	GB16806-2005
