Dahua

IR Illuminator

Name: IR Illuminator
Brand: Dahua
SKU: ITALF-300AD-IR

Stock Code: ITALF-300AD-IR

It lights camera snapshots in the dark with a xenon flash.

An IR xenon illuminator that works alongside traffic enforcement cameras. It lights the area between 16 m and 26 m, keeps the snapshot synchronized with the flash, and adjusts brightness to the site.

16 m–26 mIllumination distance

64 GNExposure

≤ 60 msRecycle time

≤ 4000 lxCenter illuminance

220 V ACPower supply

IP66Protection Grade

Key features

Xenon flashThe IR xenon illuminator lights consecutive snapshots with a flash duration of 180 µs–500 µs.

TriggeringIt switches between pulse width triggering and edge triggering, and filters interference by detecting pulse signals of fixed width.

Brightness and night settingIt sets brightness across levels 1–16 and day/night sensitivity across levels 1–6.

Spot coverageAt an installation height of 6 m it lights a 4 m wide spot at a capture distance of 26 m.

Remote monitoringIt displays running and fault status on the web interface of traffic enforcement cameras.

Lifespan and statisticsIt counts flashes and trigger times, and withstands more than 10 million flashes.

Basic
Illuminator Type	IR xenon illuminator
Recycle Time	≤ 60 ms, meeting the time requirements of taking 2 snapshots consecutively by the camera
Spot Coverage	4 m (13.12 ft) (installation height: 6 m (19.69 ft), capture distance: 26 m (85.30 ft))
Center Illuminance	≤ 4000 lx
Trigger Mode	Pulse width trigger/edge trigger
Illumination Distance	16 m–26 m (52.49 ft–85.30 ft)
Xenon
Exposure	64 GN
Flash Duration	180 µs–500 µs
Flashing Statistics	Supports statistics of flashing times and trigger times
Lifespan	≥ 10 million times
Light Source	Visible light
Function
Day/Night	Yes. Sensitivity levels 1–6 can be set
Remote Fault Display	Supports remotely displaying the running or fault status of the illuminator on the web interface of camera (only Dahua traffic enforcement cameras)
Brightness	Yes. Sensitivity levels 1–16 can be set
Capture and Flash Synchronization	Yes
False Trigger Shielding	Yes
Anti-interference	Filters interference signal by detecting pulse width signals of fixed width
Port
I/O	1
Flash	1
RS-485	1
General
Power Supply	220 V AC ±10%
Power Consumption	Xenon: < 65 J/time, instantaneous power ≤ 5500 W
Operating Temperature	–40 °C to +70 °C (–40 °F to +158 °F)
Operating Humidity	10%–90% (non-condensation)
Protection Grade	IP66
Dimensions	358.5 mm × 251.6 mm × 170.8 mm (14.11" × 9.91" × 6.72") (L × W × H)
Net Weight	4.5 kg (9.92 lb)
Gross Weight	5.0 kg (11.02 lb)
Installation	Installed on pole by using bracket

Datasheet

ITALF-300AD-IR

pdf10/27/2021

A&E Dökümanları

ITALF-300AD-IR

docx5/9/2025

Firmware

ITALF-300AD-IR

zip3/20/2024

Kullanım Kılavuzu

ITALF-300AD-IR

pdf3/20/2024

Teknik Çizim

ITALF-300AD-IR

pdf3/20/2024

Fotoğraf

ITALF-300AD-IR

png10/27/2021
