Reads IC cards at the door panel and opens access.
An IC card reader module for modular door panels. It reads Mifare 13.56 MHz cards, works outdoors behind an aluminum alloy front and draws power from the other modules on the panel.
Card readerIt reads Mifare 13.56 MHz IC cards and serves as the card access module of the panel.
PowerThe module draws 5 VDC from the other modules on the panel.
Power consumptionIt draws ≤0.2 W in standby and ≤2 W while working.
ProtectionRated IP65 and IK07; installation needs silicone sealant.
TemperatureIt operates between -30 °C and +60 °C.
MountingThe same body fits both flush and surface mounting.
