Carries data in both directions over a single fiber at distances up to 20 km.
A single-mode optical module that plugs into the SFP slot of a network switch. It runs at 1.25G, transmits at 1550 nm and receives at 1310 nm, combining upstream and downstream traffic on one fiber. Its LC interface supports backbone and edge links reaching 20 km.
1.25GData rate
20 kmTransmission distance
1550 / 1310 nmWavelength (TX / RX)
LCOptical port type
Single fiber, single-modeFiber Type
-40 °C ~ +85 °COperating Temperature
Key features
Single fiber bi-directional transmissionCarries send and receive traffic on one fiber strand, so a second strand never has to be pulled.
20 km reachReaches a device up to 20 km away over single-mode fiber.
LC optical interfacePlugs directly into single-mode fiber runs terminated with LC connectors.
Wide temperature rangeWorks from -40 °C to +85 °C and takes the temperature swings inside unheated field cabinets.
1.25G data rateMoves IP camera and recorder traffic onto the fiber backbone.
