Артикул: EAP111
| Key Features | |
|---|---|
| Wireless Bands | Concurrent dual-band 2.4 GHz and 5 GHz |
| MU-MIMO | 2x2:2 uplink and downlink MU-MIMO; up to 3 Gbps aggregate data rate |
| IoT Support | BLE / Zigbee / Thread support |
| Ports | 1 x GbE PoE WAN, 1 x GbE LAN |
| Protection Rating | IP55 |
| Management | Supports ecCLOUD |
| Wi-Fi | |
| Standards | 802.11a/b/g/n/ac/ax (Wi-Fi 6) Concurrent dual-band 2.4 GHz and 5 GHz |
| Supported Data Rates | 802.11b: 1, 2, 5.5, 11 Mbps 802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11n: 6.5 - 300 Mbps (20 / 40 MHz) 802.11ac: 6.5 - 867 Mbps (20 / 40 / 80 MHz) 802.11ax: 3.6 - 574 Mbps (2.4 GHz, 20 / 40 MHz) 802.11ax: 3.6 - 2402 Mbps (5 GHz, 20 / 40 / 80 / 160 MHz) |
| Radio Chains | 2.4 GHz: 2 x 2 5 GHz: 3 x 3 |
| Spatial Streams | 2; uplink and downlink MU-MIMO support |
| Aggregate Conducted Transmit Power | 2.4 GHz: Up to 25.5 dBm 5 GHz: Up to 25 dBm (RF output power aggregates across MIMO chains and does not include antenna gain; maximum power is limited by local regulatory requirements) |
| Channelization | 2.4 GHz: 20 / 40 MHz 5 GHz: 20 / 40 / 80 / 160 MHz |
| Frequency Range | 2.401 - 2.483 GHz 5.170 - 5.835 GHz |
| Operating Channels | 2.4 GHz: 1-11 (US), 1-13 (Europe, Japan) 5 GHz: 36-165 (US), 36-140 (Europe), 36-144 (Japan) (Some channels are restricted by local regulatory requirements and certifications) |
| ESSIDs | Up to 16 per radio (32 in total) |
| Antenna | |
| Type | Built-in antenna |
| Gain | 4.9 dBi (2.4 GHz), 5.8 dBi (5 GHz), 5.2 dBi (BLE) |
| Mechanical | |
| Dimensions (L x W x H) | 170 mm (L) x 185 mm (W) x 39.45 mm (H) |
| Weight | 0.63 kg |
| Mounting | Wall / ceiling mount (mounting kit included), pole mount (mounting kit and hose clamp optional) |
| Anti-theft | 1 x Kensington lock slot |
| Hardware | |
| Power | DC input: 12 V / 2.0 A (power adapter not included) PoE: 802.3at compliant (PoE injector not included) |
| LED Indicator | 1 x tri-color LED: Power, cloud status, uplink |
| Buttons | Restart / reset |
| Environmental Conditions | Operating temperature: 0°C (32°F) to 45°C (113°F) Operating humidity: 5% to 95% non-condensing IP55 rating |
| Power Consumption | 21.4 W max. |
| Physical Data Rate | Up to 574 Mbps (2.4 GHz) Up to 2402 Mbps (5 GHz) |
| Interface | |
| Uplink | 1 x 10/100/1000Base-T Ethernet, Auto MDIX, RJ-45 with 802.3at PoE |
| LAN | 1 x 10/100/1000Base-T Ethernet, Auto MDIX, RJ-45 |
| Certifications | |
| Certifications | FCC, IC, CE, LVD, TELEC, VCCI, NCC, BSMI |
| Wireless Features | |
| Features | 802.11 k/v/r Orthogonal Frequency Division Multiple Access (OFDMA) Client isolation Open Mesh (not in the first release) BSS Coloring Band Steering Wi-Fi Enhanced Open (OWE) Wireless site survey |
| Network Features | |
| Features | Spanning Tree Protocol (STP) Dynamic Host Configuration Protocol (DHCP) 802.1q Access Control List (ACL) Network Address Translation (NAT) |
| Security | |
| Security Standards | WPA-Personal (AES) WPA-Enterprise (AES) WPA2-Personal (AES) WPA2-Enterprise (AES) WPA3-Personal (AES) WPA3-Personal Transition (AES) WPA3-Enterprise Transition (AES) L3 Firewall |
| Maintenance | |
| Management Features | Network Time Protocol (NTP) Standalone Management by ecCLOUD Management by ecCLOUD-VPC Management by EWS/VEWS Series Controller (complete tunnel / split tunnel) SSH QR Code Onboarding Remote Syslog Zero Touch Provisioning (ZTP) |
| QoS | |
| QoS Features | RSSI threshold (optimal client filtering) Multicast-to-Unicast Conversion WME |
| Others | |
| Other Features | Target Wake Time (TWT) iBeacon |
