| Camera |
|---|
| Image Sensor | 1/2.8" STARVIS™ CMOS |
| Effective Pixels | 1920(H) × 1080(V), 2 Megapixels |
| Scanning System | Progressive |
| Electronic Shutter Speed | PAL: 1/3s ~ 1/30,000s; NTSC: 1/4s ~ 1/30,000s |
| Minimum Illumination | Color: 0.05Lux@F1.6; B/W: 0.005Lux@F1.6; 0Lux@F1.6 (IR on) |
| S/N Ratio | More than 55dB |
| IR Distance | Distance up to 150m (492ft) |
| IR On/Off Control | Auto / Manual |
| IR LEDs | 4 |
| Lens |
|---|
| Focal Length | 4.5mm ~ 135mm |
| Max. Aperture | F1.6 ~ F5.0 |
| Angle of View | H: 67.8° ~ 2.4° |
| Optical Zoom | 30× |
| Focus Control | Auto / Manual |
| Close Focus Distance | 100mm ~ 1000mm |
| DORI Distance |
|---|
| DORI | | Detect | Observe | Recognize | Identify |
|---|
| 1862m (6109ft) | 744m (2441ft) | 372m (1220ft) | 186m (610ft) |
|
| PTZ |
|---|
| Pan/Tilt Range | Pan: 0° ~ 360° endless; Tilt: -15° ~ 90°, auto flip 180° |
| Manual Control Speed | Pan: 0.1° ~ 300°/s; Tilt: 0.1° ~ 200°/s |
| Preset Speed | Pan: 400°/s; Tilt: 300°/s |
| Presets | 300 |
| PTZ Mode | 5 Pattern, 8 Tour, Auto Pan, Auto Scan |
| Speed Setup | Human-oriented focal length / speed adaptation |
| Power up Action | Auto restore to previous PTZ and lens status after power failure |
| Idle Motion | Activate Preset / Scan / Tour / Pattern if there is no command in the specified period |
| Protocol | DH-SD, Pelco-P/D (Auto recognition) |
| Video |
|---|
| Resolution | 1080P (1920×1080) / 720P (1280×720) |
| Frame Rate | 25/30fps @ 1080P; 25/30/50/60fps @ 720P |
| Video Output | 1-channel BNC high definition video output / CVBS standard definition video output (switchable) |
| Day/Night | Auto (ICR) / Color / B/W |
| OSD Menu | Support |
| Backlight Compensation | BLC / HLC / WDR (120dB) |
| White Balance | Auto, ATW, Indoor, Outdoor, Manual |
| Gain Control | Auto / Manual |
| Noise Reduction | Ultra DNR (2D / 3D) |
| Digital Zoom | 16× |
| Flip | 180° |
| Privacy Masking | Up to 24 areas |
| Certifications |
|---|
| Certifications | CE: EN55032 / EN55024 / EN50130-4; FCC: Part15 subpartB, ANSI C63.4-2014; UL: UL60950-1 + CAN/CSA C22.2, No.60950-1 |
| Interface |
|---|
| Video Interface | 1 |
| Audio Interface | 1 channel in |
| RS485 | 1 |
| Alarm I/O | 2 / 1 |
| Electrical |
|---|
| Power Supply | AC24V / 3A (±10%) |
| Power Consumption | 13W; 23W (IR on) |
| Environmental |
|---|
| Operating Conditions | -40°C ~ 70°C (-40°F ~ +158°F) / Less than 95% RH |
| Ingress Protection | IP66 |
| Vandal Resistance | N/A |
| Construction |
|---|
| Casing | Metal |
| Dimensions | 186mm × 309mm |
| Net Weight | 3.9kg (8.60lb) |
| Gross Weight | 7.2kg (15.87lb) |
