| Camera |
|---|
| Image Sensor | 1/2.8" CMOS |
| Effective Pixels | 1920(H) × 1080(V), 2 Megapixels |
| RAM/ROM | 1024M/64M |
| Scanning System | Progressive |
| Electronic Shutter Speed | 1/1 s ~ 1/30,000 s |
| Minimum Illumination | Color: 0.05 Lux@F1.6; 0 Lux@F1.6 (IR on) |
| S/N Ratio | More than 55 dB |
| IR Distance | Distance up to 300 m (984 ft) |
| IR On/Off Control | Auto/Manual |
| Illuminator Number (IR LEDs) | 4 |
| Lens |
|---|
| Focal Length | 7.9 mm ~ 316 mm |
| Max. Aperture | F1.6 ~ F6.1 |
| Angle of View | H: 41.5° ~ 1.1° |
| Optical Zoom | 40x |
| Focus Control | Auto/Manual |
| Close Focus Distance | 100 mm ~ 1000 mm |
| DORI Distance |
|---|
| Note: The DORI distance is a "general proximity" of distance which makes it easy to pinpoint the right camera for your needs. The DORI distance is calculated based on sensor specification and lab test result according to EN 62676-4 which defines the criteria for Detect, Observe, Recognize and Identify respectively. |
| Detect | Observe | Recognize | Identify |
|---|
| 3571 m (11716 ft) | 1428 m (4685 ft) | 714 m (2343 ft) | 357 m (1171 ft) |
|
| PTZ |
|---|
| Pan/Tilt Range | Pan: 0° ~ 360° endless; Tilt: -90° ~ 45° |
| Manual Control Speed | Pan: 0.1° ~ 160°/s; Tilt: 0.1° ~ 60°/s |
| Preset Speed | Pan: 160°/s; Tilt: 60°/s |
| Presets | 300 |
| PTZ Mode | 5 Pattern, 8 Tour, Auto Pan, Auto Scan |
| Speed Setup | Human-oriented focal length / speed adaptation |
| Power up Action | Auto restore to previous PTZ and lens status after power failure |
| Idle Motion | Activate Preset/Scan/Tour/Pattern if there is no command in the specified period |
| Protocol | DH-SD, Pelco-P/D (Auto recognition) |
| Intelligence |
|---|
| Auto Tracking | Support |
| IVS | Tripwire, Intrusion, Abandoned/Missing, Face Detection, Heat Map |
| Video |
|---|
| Compression | H.264 / MJPEG |
| Streaming Capability | 3 Streams |
| Resolution | 1080P (1920×1080) / 720P (1280×720) / D1 (704×576 / 704×480) / CIF (352×288 / 352×240) |
| Frame Rate | Main stream: 1080P (1 ~ 25/30 fps), 720P (1 ~ 50/60 fps); Sub stream 1: D1/CIF (1 ~ 25/30 fps); Sub stream 2: 1080P/720P/D1/CIF (1 ~ 25/30 fps) |
| Bit Rate Control | CBR/VBR |
| Bit Rate | H.264: 448K ~ 8192 Kbps, MJPEG: 4096K ~ 20480 Kbps |
| Day/Night | Auto (ICR) / Color / B/W |
| Backlight Compensation | BLC / HLC / DWDR |
| White Balance | Auto, ATW, Indoor, Outdoor, Manual |
| Gain Control | Auto / Manual |
| Noise Reduction | Ultra DNR (2D/3D) |
| Motion Detection | Support |
| Region of Interest | Support |
| Electronic Image Stabilization (EIS) | Support |
| Defog | Support |
| Digital Zoom | 16x |
| Flip | 180° |
| Privacy Masking | Up to 24 areas |
| Audio |
|---|
| Compression | G.711a / G.711mu / G.726 / AAC |
| Network |
|---|
| Ethernet | RJ-45 (10Base-T/100Base-TX) |
| Protocol | IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPoE, DDNS, FTP, IP Filter, QoS, Bonjour, 802.1x |
| Interoperability | ONVIF, PSIA, CGI |
| Streaming Method | Unicast / Multicast |
| Max. User Access | 20 users |
| Edge Storage | Local PC for instant recording, Micro SD card 128 GB |
| Web Viewer | IE, Chrome, Firefox, Safari |
| Management Software | Smart PSS, DSS |
| Smart Phone | iOS, Android |
| Certifications |
|---|
| Certifications | CE: EN55032/EN55024/EN50130-4; FCC: Part15 subpart B, ANSI C63.4-2014; UL: UL60950-1+CAN/CSA C22.2, No.60950-1 |
| Interface |
|---|
| Video Interface | 1 port (BNC, 1.0V[p-p], 75Ω) |
| RS485 | 1 |
| Audio I/O | 1/1 |
| Alarm I/O | 7/2 |
| Electrical |
|---|
| Power Supply | AC24V/5A (±25%) |
| Power Consumption | 50 W; 75 W (IR on, Heater on) |
| Environmental |
|---|
| Operating Conditions | -40°C ~ 70°C (-40°F ~ +158°F) / Less than 95% RH |
| Ingress Protection | IP66 |
| Vandal Resistance | N/A |
| Construction |
|---|
| Casing | Metal |
| Dimensions | Φ202.7 mm × 390.8 mm × 472.2 mm |
| Net Weight | 10.5 kg (23.15 lb) |
| Gross Weight | 16.5 kg (36.38 lb) |
