| Camera |
|---|
| Image Sensor | 1/2.8" Exmor CMOS |
| Effective Pixels | 2.42 Megapixels |
| Electronic Shutter Speed | 1/1 ~ 1/30,000 s |
| S/N Ratio | More than 55dB |
| Day/Night | Auto(ICR) / Color / B/W |
| White Balance | BLC / HLC / DWDR |
| Gain Control | Auto, ATW, Indoor, Outdoor, Manual |
| Noise Reduction | Auto / Manual |
| Optical Zoom | 2D / 3D |
| Lens |
|---|
| Focal Length | 4.5mm ~ 135mm |
| Max. Aperture | F1.6 ~ F4.4 |
| Focus Control | Auto / Manual |
| Angle of View | H: 67.8° ~ 2.77° |
| Video |
|---|
| Compression | H.264 / MJPEG |
| Resolution | 1080P (1920×1080) / 720P (1280×720) / D1 (704×576 / 704×480) / CIF (352×288 / 352×240) |
| Frame Rate | Main Stream: 25/30fps@1080P / 720P; Sub Stream: 25/30fps@D1/CIF |
| Bit Rate | H.264: 56K ~ 8192Kbps; MJPEG: 56K ~ 20480Kbps |
| Network |
|---|
| Ethernet | RJ-45 (10/100M) |
| Protocol | IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour |
| ONVIF | ONVIF Profile S |
| Max. User Access | 32 users |
| Smart Phone | iPhone, iPad, Android, Windows Phone |
| PTZ |
|---|
| Pan Range | 360° endless |
| Pan Speed | 0.1° ~ 80°/sec |
| Tilt Range | -90° ~ 90° |
| Tilt Speed | 0.1° ~ 60°/sec |
| Positioning Accuracy | ±0.01° |
| Preset | 255 |
| Tour | 8 |
| Pattern | 5 |
| Auto Scan | 5 |
| Preset Auto-Calibration | Support |
| Remote P/T/Z Reset | Support |
| Wiper | Support |
| IR Distance | 150m |
| General |
|---|
| Power Supply | DC 12V (10.8V ~ 18V) |
| Power Consumption | <60W |
| Working Environment | -30°C ~ 65°C / Less than 95% RH |
| Protection | IP66, All-metal aluminum alloy, 6000V anti-lightning surge |
| Dimension | 375mm × 248mm × 210mm |
| Weight | 7.5Kg |
