Stock Code: PTZ85848-HNF-PA
| Camera | |
|---|---|
| Image Sensor | 1/1.8" CMOS |
| Pixel | 8 MP |
| Max. Resolution | 3840 (H) × 2160 (V) |
| ROM | 8 GB |
| RAM | 2 GB |
| Electronic Shutter Speed | 1/1 s – 1/30,000 s |
| Scanning System | Progressive |
| Min. Illumination | Color: 0.005 lux@F1.4; B/W: 0.0005 lux@F1.4; 0 lux (IR light on) |
| Illumination Distance | 400 m (1,312.34 ft) (IR) |
| Illuminator Control | Zoom Prio; Manual; Off |
| Illuminator Number | 8 (IR) |
| Wiper | Yes |
| Lens | |
| Focal Length | 6.25 mm – 300 mm |
| Max. Aperture | F1.4 – F4.5 |
| Field of View | H: 64.9° – 1.8°; V: 38° – 1.3°; D: 71.3° – 1.9° |
| Optical Zoom | 48× |
| Focus Control | Auto; semi-auto; manual |
| Close Focus Distance | 0.5 m – 2 m (1.64 ft – 6.56 ft) |
| Iris Control | Auto; manual |
| DORI Distance | |
| Detect | 6,000 m (19,685.04 ft) |
| Observe | 2,381 m (7,811.68 ft) |
| Recognize | 1,200 m (3,937.01 ft) |
| Identify | 600 m (1,968.50 ft) |
| PTZ | |
| Pan/Tilt Range | Pan: 0° – 360° endless; Tilt: –45° – +90° |
| Manual Control Speed | Pan: 0.1°/s – 160°/s; Tilt: 0.1°/s – 60°/s |
| Preset Speed | Pan: 160°/s; Tilt: 60°/s |
| Preset | 300 |
| Tour | 8 (up to 32 presets per tour) |
| Pattern | 5 |
| Scan | 5 |
| Power-off Memory | Yes |
| Idle Motion | Preset; Pattern; Tour; Scan |
| PTZ Protocol | DH-SD; Pelco-P/D (auto recognition) |
| Intelligence | |
| Video Metadata | Support human body, human face, motor vehicle and non-motor vehicle capture |
| IVS (Perimeter Protection) | Tripwire; intrusion; climbing fences; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; vehicle/human alarm classification |
| Face Recognition | Yes |
| Video | |
| Video Compression | H.265; H.264M; H.264H; MJPEG; Smart H.265; Smart H.264 |
| Stream Number | 3 |
| Resolution | 8M, 4M, 1080p, 960p, 720p, D1, VGA, CIF |
| Video Frame Rate | Main stream: 1–25/30 fps (8M, 4M, 1080p, 960p, 720p); Sub stream 1: 1–25/30 fps (D1, VGA, CIF); Sub stream 2: 1–25/30 fps (1080p, 960p, 720p) |
| Bit Rate Control | CBR; VBR |
| Video Bit Rate | H.264: 3328–16384 kbps; H.265: 1280–9984 kbps |
| Day/Night | Auto (ICR); Color; B/W |
| BLC | Yes |
| WDR | DWDR |
| HLC | Yes |
| White Balance | Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp |
| Gain Control | Auto; manual |
| Noise Reduction | 2D NR; 3D NR |
| Motion Detection | Yes |
| ROI | Yes |
| Defog | Optical |
| Digital Zoom | 16× |
| Image Rotation | 180° |
| Privacy Masking | Up to 24 areas can be set, with up to 8 areas in the same view |
| S/N Ratio | ≥55 dB |
| Audio | |
| Audio Compression | G.711a; G.711Mu; G.726; MPEG2-Layer2; G722.1; G729; PCM |
| Network | |
| Network Port | RJ-45 (10/100 Base-T) |
| Network Protocol | HTTP; HTTPS; IPv4; RTSP; UDP; SMTP; NTP; DHCP; DNS; DDNS; IPv6; 802.1x; QoS; FTP; UPnP; ICMP; SNMP; IGMP; RTP; PPPoE; RTMP; TCP |
| Interoperability | ONVIF (Profile S&G&T); GB/T28181; CGI |
| Streaming Method | Unicast; Multicast |
| Max. User/Host | 20 (total bandwidth 64 M) |
| Edge Storage | FTP; Micro SD card (512 GB); NAS |
| Browser | IE 7 and later; Chrome 45 and later; Firefox 52ESR and earlier; Safari |
| Management Software | Smart PSS; DSS; IVSS |
| Mobile Client | iOS; Android |
| Ports | |
| Analog Output | 1 channel (CVBS output, BNC) |
| RS-485 | 1 (1200 bps – 115200 bps) |
| Audio Input / Output | 1 channel LINE IN (bare wire); 1 channel LINE OUT (bare wire) |
| Two-way Audio | Yes |
| Alarm Input / Output | 7 input (on-off value: 0–5 VDC); 2 output |
| Alarm Linkage | Capture; preset; tour; pattern; recordings on SD card; alarm digital input; client E-map; send email |
| Alarm Event | Motion/tampering detection; audio detection; network disconnection detection; IP conflict detection; decoder state detection; memory card state detection; memory space detection; power exception detection |
| Power | |
| Power Supply | 36 VDC, 5 A (± 25%) |
| Power Consumption | Basic: 22 W; Max.: 63 W (illuminator + wiper + PTZ) |
| Environmental | |
| Operating Temperature | –40 °C – +70 °C (–40 °F – 158 °F) |
| Operating Humidity | ≤95% |
| Protection | IP67; TVS 6000 V lightning proof; surge protection; voltage transient protection |
| Construction | |
| Casing | ADC12 |
| Dimensions | 344.6 mm × 252.2 mm × 499.8 mm (13.57" × 9.93" × 19.68") (L × W × H) |
| Net Weight | 15.4 kg (33.95 lb) |
| Gross Weight | 23.7 kg (52.25 lb) |
