Adds a 4-pin Mini XLR connection to the device panel
A female Mini XLR connector that sits on the device panel with its square chassis body. It handles the 4-pole signal connection on the panel in professional audio and lighting systems.
4Pin Count
FemaleGender
ChassisMounting Type
StampedContact Type
5 ACurrent Capacity
5000Mating Cycles
Key features
Series and equivalentBelongs to the Mini XLR G type series; the comparable part number is TY4F.
Contacts and shellNickel plated stamped socket contacts and a nickel plated diecast shell withstand 5000 mating cycles.
Wire gaugeAccepts conductors up to 24 AWG – 0.5 mm².
Electrical ratingsCarries a rated current of 5 A at 40°C and a rated voltage of 50 V.
Temperature and complianceOperates between -30°C and +80°C and complies with the EU RoHS 2 (2011/65/EU) directive.
Usage areasRadio and TV broadcasting·Professional studios·Sound reinforcement and PA·Musicians and DJs·Special applications
