| Camera |
|---|
| Image Sensor | 1/2.8" CMOS |
| Pixel | 4MP |
| Max. Resolution | 2560 (H) × 1440 (V) |
| ROM | 4 GB |
| RAM | 1 GB |
| Electronic Shutter Speed | 1/1 s–1/30000 s |
| Scanning System | Progressive |
| Min. Illumination | Color: 0.005 Lux@F1.8; B/W: 0.0005 Lux@F1.8; 0 Lux (IR on) |
| Illumination Distance | 40 m (131.23 ft) |
| Illuminator On/Off Control | Zoom Prio/Manual/SmartIR/Off |
| Illuminator Number | 3 IR lights |
| Lens |
|---|
| Focal Length | 2.8 mm–12 mm |
| Max. Aperture | F1.8–F2.7 |
| Field of View | H: 42.8°–91.9°; V: 23.8°–49.4°; D: 49.1°–109.4° |
| Optical Zoom | 4x |
| Focus Control | Auto/Semi-Auto/Manual |
| Close Focus Distance | 0.2 m–0.5 m (0.66 ft–1.64 ft) |
| Iris Control | Fixed |
| DORI Distance | | Detect | Observe | Recognize | Identify |
|---|
| 240 m (787.40 ft) | 95 m (311.68 ft) | 48 m (157.48 ft) | 24 m (78.74 ft) |
|
| PTZ |
|---|
| Preset | 300 |
| Power-off Memory | Support |
| Idle Motion | Preset |
| Artificial Intelligence |
|---|
| Smart Capture | Support human, motor vehicle and non-motor vehicle image capture. |
| Perimeter Protection | Tripwire and intrusion. Support alarm triggering by target types (human and vehicle). Support filtering false alarms caused by animals, rustling leaves, bright lights, etc. |
| Face Detection | Support |
| Video |
|---|
| Compression | H.265; H.264B; H.264M; H.264H; MJPEG; H.265+; H.264+ |
| Streaming Capability | 3 streams |
| Resolution | 4M (2560 × 1440); 3M (2048 × 1536); 1080P (1920 × 1080); 1.3M (1280 × 960); 720P (1280 × 720); D1 (704 × 576); CIF (352 × 288) |
| Frame Rate | Main stream: 4M/3M/1080P/960P/720P (1–25/30 fps); Sub stream 1: D1/CIF (1–25/30 fps); Sub stream 2: 1080P/960P/720P (1–25/30 fps) |
| Bit Rate Control | Variable/Constant |
| Bit Rate | H.264: 2816 Kbps–8192 Kbps |
| Day/Night | Auto (ICR)/Color/B/W |
| BLC | Support |
| WDR | 120 dB |
| HLC | Support |
| White Balance | Auto/Indoor/Outdoor/Tracking/Manual/Sodium lamp/Natural light/Street lamp |
| Gain Control | Auto/Manual |
| Noise Reduction | 2D/3D |
| Motion Detection | Support |
| Region of Interest (RoI) | Support |
| Image Stabilization | Electronic |
| Defog | Electronic |
| Digital Zoom | 16x |
| Flip | 180° |
| Privacy Masking | Up to 24 areas, and up to 8 areas in the same view |
| S/N Ratio | 55 dB |
| Audio |
|---|
| Compression | G.711a; G.711Mu; G.726; AAC; MPEG2-Layer2; G722.1; G729; G723 |
| Network |
|---|
| Ethernet | 1 (crystal head, 10/100Base-T) |
| Protocol | IPv4; IPv6; HTTP; HTTPS; 802.1x; QoS; FTP; SMTP; UPnP; SNMP; DNS; DDNS; NTP; RTSP; RTP; TCP; UDP; IGMP; ICMP; DHCP; PPPoE; ARP; SNMP v1/v2c/v3 (MIB-2); RTCP; RTMP |
| Interoperability | ONVIF (Profile S&G&T); CGI |
| Streaming Method | Unicast/Multicast |
| User/Host | 20 |
| Storage | FTP; Micro SD card (256G); NAS |
| Browser | IE7 and later versions; Chrome 42 and earlier versions; Firefox 52 and earlier versions; Safari |
| Management Software | Smart PSS; DSS; DMSS; IVSS |
| Mobile Phone | iOS; Android |
| Certification |
|---|
| Certifications | CE: EN55032/EN55024/EN50130-4; FCC: Part15 subpartB, ANSI C63.4-2014; ATEX: II 2 G Ex db IIC T6 Gb, II 2 D Ex tb IIIC T80°C Db; IECEx: Ex db IIC T6 Gb, Ex tb IIIC T80°C Db |
| Port |
|---|
| Audio Input | 1 |
| Audio Output | 1 |
| Two-way Audio | Support |
| Alarm Linkage | Capture; preset; record; alarm digital output; audio; send email |
| Alarm Event | Motion/tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection; abnormal power supply detection |
| Optical Fiber | 100M single fiber. Transmission specification: 1310nm TX/1550nm RX. Distance: 20 km (65616.80 ft) |
| Power |
|---|
| Power Supply | DC12V/1.5A±10% |
| Power Consumption | Basic: 4W; Max.: 9W (IR light on) |
| Environment |
|---|
| Operating Temperature | –40°C to +60°C (–40°F to +140°F) |
| Operating Humidity | ≤ 95% |
| Protection | IP68; TVS 6000V lightning proof; surge protection; voltage transient protection |
| Structure |
|---|
| Casing | SUS304/SUS316L (customizable) |
| Dimensions | 215 mm × 149 mm × 151 mm (8.46" × 5.87" × 5.94") (L × W × H) |
| Net Weight | 3 kg (6.61 lb) |
| Gross Weight | 6.3 kg (13.89 lb) |
