Stock Code: IPC-HDEW8841R-Z
| Camera | ||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Image Sensor | 1/2.8" CMOS | |||||||||||||||
| Max. Resolution | 3840 (H) × 2160 (V) | |||||||||||||||
| ROM | 128 MB | |||||||||||||||
| RAM | 1 GB | |||||||||||||||
| Scanning System | Progressive | |||||||||||||||
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s | |||||||||||||||
| Min. Illumination | 0.007 lux@F1.5 (Color, 30 IRE) 0.0007 lux@F1.5 (B/W, 30 IRE) 0 lux (Illuminator on) | |||||||||||||||
| S/N Ratio | >56 dB | |||||||||||||||
| Illumination Distance | 40 m (131.23 ft) (IR LED) | |||||||||||||||
| Illuminator On/Off Control | Auto; Manual | |||||||||||||||
| Illuminator Number | 2 (IR LED) | |||||||||||||||
| Pan/Tilt/Rotation Range | Pan: 0°–355° Tilt: 0°–75° Rotation: 0°–355° | |||||||||||||||
| Lens | ||||||||||||||||
| Lens Type | Motorized vari-focal | |||||||||||||||
| Lens Mount | φ14 | |||||||||||||||
| Focal Length | 2.7 mm–13.5 mm | |||||||||||||||
| Max. Aperture | F1.5 | |||||||||||||||
| Field of View | H: 109°–30°; V: 56°–17°; D: 131°–35° | |||||||||||||||
| Iris Control | Fixed | |||||||||||||||
| Close Focus Distance | 0.8 m (2.62 ft) | |||||||||||||||
| DORI Distance |
| |||||||||||||||
| Smart Event | ||||||||||||||||
| IVS | Abandoned object; missing object | |||||||||||||||
| Intelligence | ||||||||||||||||
| IVS (Perimeter Protection) | Intrusion, tripwire, fast moving (the three functions support the classification and accurate detection of vehicle and human); loitering detection, people gathering, and parking detection | |||||||||||||||
| SMD 3.0 | Less false alarm, longer detection distance | |||||||||||||||
| Face Detection | Face detection; track; snapshot; snapshot optimization; optimal face snapshot upload; face enhancement; face exposure; face attributes extraction including 6 attributes (gender, age, glasses, expressions, mask, and beard) and 8 expressions (angry, sad, disgusted, scared, surprised, calm, happy, confused); face snapshot set as face or one-inch photo; snapshot strategies (real-time snapshot, quality priority and optimization snapshot); face angle filter; optimization time setting. | |||||||||||||||
| People Counting | Tripwire people counting, generating and exporting report (day/month/year); people counting in area; queue management; 4 rules can be set for tripwire, people counting in area and queue management. | |||||||||||||||
| Heat Map | Yes | |||||||||||||||
| Smart Search | Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos | |||||||||||||||
| Video | ||||||||||||||||
| Video Compression | H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream) | |||||||||||||||
| Smart Codec | Smart H.265+; Smart H.264+ | |||||||||||||||
| AI Coding | AI H.265 / AI H.264 | |||||||||||||||
| Video Frame Rate | Main stream: 3840 × 2160@(1–25/30 fps) Sub stream: 704 × 576@(1–25 fps)/704 × 480@(1–30 fps) Third stream: 1920 × 1080@(1–25/30 fps) *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. | |||||||||||||||
| Stream Capability | 3 streams | |||||||||||||||
| Resolution | 8M (3840 × 2160); 6M (3072 × 2048); 5M (3072 × 1728/2592 × 1944); 4M (2688 × 1520); 3.6M (2560 × 1440); 3M (2048 × 1536); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1920 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) | |||||||||||||||
| Bit Rate Control | CBR/VBR | |||||||||||||||
| Video Bit Rate | H.264: 32 kbps–16384 kbps H.265: 32 kbps–16384 kbps | |||||||||||||||
| Day/Night | Auto (ICR)/Color/B/W | |||||||||||||||
| BLC | Yes | |||||||||||||||
| HLC | Yes | |||||||||||||||
| WDR | 120 dB | |||||||||||||||
| Scene Self-adaptation (SSA) | Yes | |||||||||||||||
| White Balance | Auto; natural; street lamp; outdoor; manual; regional custom | |||||||||||||||
| Gain Control | Auto | |||||||||||||||
| Noise Reduction | 3D NR | |||||||||||||||
| Motion Detection | OFF/ON (4 areas, rectangular) | |||||||||||||||
| Region of Interest (RoI) | Yes (4 areas) | |||||||||||||||
| Image Stabilization | Electronic Image Stabilization (EIS) | |||||||||||||||
| Defog | Yes | |||||||||||||||
| Image Rotation | 0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower) | |||||||||||||||
| Mirror | Yes | |||||||||||||||
| Privacy Masking | 4 areas | |||||||||||||||
| Audio | ||||||||||||||||
| Audio Compression | PCM; G.711a; G.711Mu; G.726; G.723 | |||||||||||||||
| Alarm | ||||||||||||||||
| Alarm Event | No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; fast moving; abandoned object; missing object; loitering detection; people gathering; parking detection; scene changing; audio detection; voltage detection; defocus detection; external alarm; face detection; SMD; people counting in area; stay detection; people counting; security exception | |||||||||||||||
| Network | ||||||||||||||||
| Network Port | RJ-45 (10/100 Base-T) | |||||||||||||||
| SDK & API | Yes | |||||||||||||||
| Network Protocol | IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP | |||||||||||||||
| Interoperability | ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone; Genetec | |||||||||||||||
| User/Host | 20 (Total bandwidth: 80 M) | |||||||||||||||
| Storage | FTP; SFTP; Micro SD card (support max. 256 GB); NAS | |||||||||||||||
| Browser | IE; Chrome; Firefox | |||||||||||||||
| Management Software | Smart PSS; DSS; DMSS | |||||||||||||||
| Mobile Client | iOS; Android | |||||||||||||||
| Cyber Security | Configuration encryption; trusted execution; Digest; Security logs; WSSE; account lockout; syslog; Video encryption; 802.1x; IP/MAC filtering; HTTPS; trusted upgrade; trusted boot; firmware encryption; generation and importing of X.509 certification | |||||||||||||||
| Certification | ||||||||||||||||
| Certifications | CE-LVD: EN62368-1; CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU; FCC: 47 CFR FCC Part 15, Subpart B; ATEX: EN 60079-0/EN 60079-1/EN 60079-31; IECEx: IEC 60079-0/IEC 60079-1/IEC 60079-31; Certificate: ATEX: TÜV 20 ATEX 8579 X; IECEx: IECEx TUR 20.0059X | |||||||||||||||
| Port | ||||||||||||||||
| RS-485 | 1 (baud rate range: 1200 bps–115200 bps) | |||||||||||||||
| Audio Input | 1 channel (terminal) | |||||||||||||||
| Audio Output | 1 channel (terminal) | |||||||||||||||
| Alarm Input | 3 channels in: 5mA 3V–5V DC | |||||||||||||||
| Alarm Output | 2 channels out: 300 mA 12 VDC | |||||||||||||||
| Power | ||||||||||||||||
| Power Supply | 12 VDC/PoE (802.3af) | |||||||||||||||
| Power Consumption | Basic: 4.0 W (12 VDC); 4.7 W (PoE) Max. (H.265 + intelligence on + WDR + IR on + auto focus): 7.3 W (12 VDC); 8.5 W (PoE) | |||||||||||||||
| Environment | ||||||||||||||||
| Operating Temperature | T5/T100 °C: –40 °C ≤ Tamb ≤ +60 °C (–40 °F to +140 °F) T6/T80 °C: –40 °C ≤ Tamb ≤ +55 °C (–40 °F to +131 °F) | |||||||||||||||
| Operating Humidity | ≤95% | |||||||||||||||
| Storage Temperature | –40 °C to +60 °C (–40 °F to +140 °F) | |||||||||||||||
| Storage Humidity | ≤95% | |||||||||||||||
| Protection | IP68; IK10 | |||||||||||||||
| Structure | ||||||||||||||||
| Casing Material | SUS316L (316 stainless steel) | |||||||||||||||
| Product Dimensions | 219.5 mm × Φ165 mm × 118.2 mm (8.64" × Φ6.50" × 4.65") (L × W × H) | |||||||||||||||
| Net Weight | 4.5 kg (9.92 lb) | |||||||||||||||
| Gross Weight | 5.3 kg (11.68 lb) | |||||||||||||||
