Stock Code: ECA2A1400-HN
| Camera | |
|---|---|
| Image Sensor | 1/2.8" CMOS |
| Pixel | 4 MP |
| Max. Resolution | 2560 (H) × 1440 (V) |
| ROM | 128 MB |
| RAM | 128 MB |
| Electronic Shutter Speed | 1/1 s–1/30,000 s |
| Scanning System | Progressive |
| Min. Illumination | Color: 0.005 lux@F1.8; B/W: 0.0005 lux@F1.8 |
| Illumination Distance | 30 m (98.43 ft) (IR) |
| Illuminator On/Off Control | Manual; Smart IR; Off |
| Illuminator Number | 1 (IR) |
| Lens | |
| Focal Length | 6 mm; 4 mm |
| Max. Aperture | F1.8 |
| Field of View | H: 49°; V: 37°; D: 61°; H: 81°; V: 59°; D: 106° |
| Optical Zoom | 1 |
| Close Focus Distance | 0.2 m (0.66 ft); 0.6 m (1.97 ft) |
| Iris Control | Auto; semi-auto; manual |
| Iris Control | Fixed |
| Smart Event | |
| IVS | Tripwire; intrusion |
| Human Detection | Yes |
| SMD | Yes |
| Video | |
| Video Compression | H.264B; Smart H.265+; H.264; H.265; MJPEG (Sub Stream); Smart H.264+ |
| Streaming Capability | 2 streams |
| Resolution | 4M (2560 × 1440); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576); CIF (352 × 288) |
| Video Frame Rate | Main stream: 4M/1080p/1.3M/720p@(1–25/30 fps) Sub stream: D1/CIF@(1–25/30 fps) |
| Bit Rate Control | CBR/VBR |
| Video Bit Rate | H.264: 32 kbps–8192 kbps H.265: 32 kbps–8192 kbps |
| Day/Night | Auto (ICR)/Color/B/W |
| BLC | Yes |
| WDR | Yes |
| HLC | Yes |
| White Balance | Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp |
| Gain Control | Auto; manual |
| Noise Reduction | 2D NR; 3D NR |
| Motion Detection | Yes |
| Image Rotation | 180° |
| S/N Ratio | ≥ 55 dB |
| Network | |
| Network Port | RJ-45 (10/100 Base-T) |
| Network Protocol | UDP;TCP;FTP;RTMP;IPv6;IPv4;IP Filter;DNS;RTCP;HTTP;NTP;SSL;DHCP;RTP;SMTP;HTTPS;TCP/IP;RTSP;DDNS;ARP |
| Interoperability | CGI; ONVIF |
| Streaming Method | Unicast/Multicast |
| User/Host | 20 |
| Storage | FTP; Micro SD card (512 GB) |
| Browser | IE 7 and later versions Chrome 42 and earlier versions Firefox 52 and earlier versions Safari |
| Management Software | Player; Smart Player; Imou; DMSS; ConfigTool; NVR; Smart PSS |
| Mobile Client | iPhone; Windows Phone; iPad; iOS; Android |
| Certification | |
| Certifications | FCC: 47 CFR FCC Part15, Subpart B, ClassA CE: EN 55032/EN IEC 61000-3-2/EN 61000-3-3/EN 55024/EN 55035/EN 50130-4/EN 62368-1 ATEX: EN 60079-0/EN 60079-1/EN60079-31 IECE: IEC 60079-0/IEC 60079-1/IEC 60079-31 |
| Port | |
| Alarm Linkage | Capture; recordings; send emails |
| Alarm Event | Motion/tampering detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection |
| Power | |
| Power Supply | 12 VDC/1.5 A ± 10% PoE (802.3af) |
| Power Consumption | Basic: 2 W Max.: 3.5 W (illuminator) |
| Environment | |
| Operating Temperature | –40 °C to +60 °C (–40 °F to +140 °F) |
| Operating Humidity | ≤95% |
| Protection | IP68 (2 m/2 h); TVS 6000V lightning proof; surge protection; voltage transient protection |
| Structure | |
| Casing Material | Stainless steel |
| Product Dimensions | 173.3 mm × 144 mm × 126.5 mm (6.82" × 5.67" × 4.98") |
| Net Weight | 2.3 kg (5.07 lb) |
| Gross Weight | 3 kg (6.61 lb) |
