Terminates the loudspeaker line at six poles on the panel
A chassis-type loudspeaker connector with male contacts that mounts onto a panel surface in audio systems. It gathers the six-pole connection inside a square-flange plastic body.
6pin count
Malecontact gender
Chassismounting type
20 Arated current
200 Vrated voltage
Key features
Contact layoutThe male contacts form 6 positions, excluding PE.
Body and flangeThe plastic body seats onto the panel surface with its square flange.
Electrical limitsIt carries 20 A of current and a 200 V rated voltage at 40 °C.
ComplianceIt conforms to the EU RoHS 2002/95/EC directive.
Usage areasRadio and TV broadcasting·Professional studios·Voice-over and PA systems·Musicians and DJs·Custom applications
