A 6.3 mm (1/4") stereo phone plug. Gold-plated tip, ring and sleeve contacts form the signal path, while the nickel-plated diecast body turns the cable to the side.
Contact platingTip, ring and sleeve carry gold plating, which protects the mating surfaces.
Right-angle bodyThe 90° body takes the cable out from the side, and the nickel-plated shell closes over the contact assembly.
DimensionsOverall body length is 61.0 mm and maximum body diameter Ø13.8 mm; the plug shaft runs 30.60 mm long at Ø6.32 mm diameter.
Cable entryA flexible grommet protects the cable, and the entry accepts cable up to 6.5 mm outer diameter.
Insulation and constructionA PVC insulator tube separates the contact assembly, and the right-angle insert, top cap and M-Series backshell complete the plug.
ComplianceRoHS compliant (EU 2002/95/EC).
