| PROPERTIES |
|---|
| Tensile Strength at Break | | Unit | kN | | Value | >1.2 | | Test Standard | EN 60794.1.E1 |
|
| Breaking Tensile Strength | | Unit | kN | | Value | >1.5 | | Test Standard | EN 60794.1.E1 |
|
| Crush Resistance | | Unit | N/cm | | Value | >200 | | Test Standard | EN 60794.1.E3 |
|
| Repeating Bending Radius | | Unit | mm | | Value | <20xD | | Test Standard | EN 60794.1.E6 |
|
| Single Bending Radius | | Unit | mm | | Value | <15xD | | Test Standard | EN 60794.1.E6 |
|
| Torsion | | Unit | +90° C,8 | | Value | Positive | | Test Standard | EN 187 000 M 508 |
|
| Impact | | Unit | kN | | Value | >1 | | Test Standard | EN 187000 M 504 |
|
| Temperature | | Test Standard | EN 60794.1.E11 |
|
| OUTER SHEATH |
|---|
| Density | | Unit | g/cm³ | | Value | >20 | | Test Standard | ASTM D 638 |
|
| Tensile Strength at Break | | Unit | N/mm² | | Value | >400 | | Test Standard | ASTM D 638 |
|
| Elongation at Break | | Unit | % | | Value | 2/10 | | Test Standard | ASTM D 1693 |
|
| E.S.C.R. (10% Igepal C-630) | | Unit | >500 hours | | Value | 2/10 | | Test Standard | ASTM D 746 |
|
| Breaking Cold | | Unit | <-75°C | | Value | 2.5+0.5 | | Test Standard | ASTM D 1603 |
|
| Carbon Black Rate | | Unit | % | | Value | <0.950 | | Test Standard | ASTM D 792 Method A |
|
| Oxygen Induction Time | | Unit | 200°C | | Value | >25 | | Test Standard | IEC 811.4.2 B |
|
| TUBE GEL |
|---|
| Density (25°C) | | Unit | g/cm³ | | Value | +0.05 | | Test Standard | DIN 51 757 |
|
| Drop Point (24 hours) | | Unit | °C | | Value | Appropriate | | Test Standard | IEC 811.5.1 B |
|
| Drip Point (24 hours) | | Unit | °C | | Value | >70 | | Test Standard | REA PE 39 |
|
| Flash Point | | Unit | °C | | Value | >230 | | Test Standard | ISO 2592 |
|
| Oil Separation (150°C, 24 hours) | | Unit | % | | Value | 0 | | Test Standard | FTM STD 791 C |
|
| Volatility | | Unit | % | | Value | <2 | | Test Standard | FTM STD 791 C |
|
| Water Amount | | Unit | % | | Value | <0.05 | | Test Standard | DIN 51 777 |
|
| Acid Value (100°C) | | Unit | % (mg KOH/g) | | Value | <0.01 | | Test Standard | DIN 53 402 |
|
| Abrasion | | Value | Positive | | Test Standard | IEC 811.5.1 |
|
| Penetration (25°C / -30°C) | | Unit | 1/10 mm | | Value | >150 | | Test Standard | ISO 2137 |
|
| Oxygen Induction Time (180°C) | | Unit | minute | | Value | >20 | | Test Standard | IEC 811.4.2 B |
|
| 100-500V (100°) | | Unit | Ω x m | | Value | >10 | | Test Standard | ASTM D 1169 |
|
| 100-500V (23°) | | Unit | Ω x m | | Test Standard | ASTM D 1169 |
|
| Loose Tube | |
| Density | | Unit | g/cm³ | | Value | 1.31+0.03 | | Test Standard | ISO 1183 |
|
| Water Absorption (23°C) | | Unit | % | | Value | <0.45 | | Test Standard | DIN 53 495 |
|
| Tensile Strength at Break | | Unit | N/mm² | | Value | <30 | | Test Standard | ISO 527 |
|
| Elongation at Break | | Unit | % | | Value | >50 | | Test Standard | ISO 527 |
|
| E-Modulus | | Unit | N/mm² | | Value | >2200 | | Test Standard | ISO 527 |
|
| Shore Hardness | | Unit | Shore D | | Value | >78 | | Test Standard | DIN 53 505 |
|
| Melting Temperature (DSC) | | Unit | °C | | Value | >220 | | Test Standard | ISO 3146 C |
|
| Lin. Thermal Ext. Coeff. (-23<<+80°C) | |
| E-GLASS YARN |
|---|
| Density | | Unit | g/cm³ | | Value | Offered | | Test Standard | Offered |
|
| Tensile Strength at Break | | Unit | % | | Value | Offered | | Test Standard | Offered |
|
| Elongation at Break | | Unit | N/mm² | | Value | Offered | | Test Standard | Offered |
|
| E-Modulus | | Unit | % | | Value | Offered | | Test Standard | Offered |
|
| ARMOURING |
|---|
| Steel Thickness | | Unit | nm | | Value | 0.155±0.015 | | Test Standard | ASTM A 623 M |
|
| Tensile Strength at Break | | Unit | N/mm² | | Value | >300 | | Test Standard | ASTM E 6892 |
|
| Elongation at Break | | Unit | % | | Value | >15 | | Test Standard | ASTM E 6892 |
|
| Thickness of Coating | | Unit | nm | | Value | >0.050±0.01 | | Test Standard | ASTM A 623 M |
|
| DC Resistance | | Unit | ohm/km | | Value | <40 | | Test Standard | ASTM A 6892 |
|
