| Hardware Specification |
|---|
| System |
|---|
| Main Processor | X86 Processor Core i3-6100 |
| Operating System | Embedded Linux |
| Memory | 8 GB |
| System Disk | Seagate 7200 RPM Enterprise Class HDD 2 TB |
| Motherboard | Embedded board (7 x 24) |
| Hard Disk Compatibility | SAS/SATA disk |
| Interface |
|---|
| Network Ports | 4 Ethernet ports (10/100/1000 Mbps) |
| USB | 1 × USB 2.0 on front panel; 2 × USB 3.0 on rear panel |
| HDMI | 2 HDMI ports |
| VGA | 1 VGA port |
| Storage |
|---|
| HDD Installation | Supports 2 HDDs (2.5") for video or picture storage |
| Storage | Up to 100 TB per server |
| HDD Mode | Single |
| Bandwidth of Video Storage per Server | 350 Mbps |
| Other |
|---|
| Power | 100 V–240 V, 47–63 Hz |
| Consumption | 70 W–120 W (with HDD) |
| Working Environment Temperature | 0 °C–45 °C (32 °F to +113 °F) |
| Working Environment Humidity | 5%–90% (RH), non-condensing |
| Storage Environment Temperature | –20 °C to +70 °C (–4 °F to +158 °F) |
| Storage Environment Humidity | 5%–90% (RH), non-condensing |
| Working Altitude | –60 m to 3,000 m (–196.85 ft to 9,842.52 ft) |
| Weight (Without Package) | 6.0 kg (13.23 lb) |
| Dimensions | 1U, 440 mm × 398.6 mm × 43.65 mm (17.32" × 15.69" × 1.72") |
| Installation Method | Standard 19-inch rack mount |
| PC Client System Requirements |
|---|
| Item | Recommended | Minimum |
|---|
| CPU | Intel® Core i7-11700 @2.50 GHz | Intel® Core i5-9500 @3.00 GHz | | Memory | 16 GB | – | | Graphics Card | NVIDIA® GeForce® RTX 3060 | Intel® UHD Graphics 630 | | Hard Drive Capacity | 100 GB Free | 50 GB Free | | Ethernet Port | 1,000 Mbps | – |
|
| Performance Specification |
|---|
| Face and Vehicle Watch Lists |
|---|
| Total Faces | 5,000 |
| Face Watch Lists | 50 |
| Vehicle Watch Lists | 8 |
| Faces per Face Watch List | 5,000 |
| Vehicles per Vehicle Watch List | 5,000 |
| Event |
|---|
| Event Sources for Event Rules | 256 |
| Combined Event Rules | 100 |
| Combined Events | 128 |
| Map |
|---|
| Hierarchies | 8 |
| Maximum Size of Raster Map | 15 MB |
| Raster Maps | 32 |
| Resources per Raster Map (After merging) | 300 |
| Resources per Raster Map (Before merging) | 2,000 |
| Person and Vehicle Management |
|---|
| Persons and Vehicle Groups | 999 |
| Group Levels | 10 |
| Persons | 5,000 |
| Cards | 10,000 |
| Faces | 5,000 |
| Fingerprints | 10,000 |
| Vehicles | 5,000 |
| Organization, Role and User |
|---|
| Roles | 20 |
| Users (PC Client and DSS Agile 8) | 10 online users and 50 total users |
| Roles per User | 32 |
| DSS Agile VDP Users | 200 online users and 2,000 total users |
| Recording Plan |
|---|
| General Recording Plans | 256 |
| Motion Detection Recording Plans | 256 |
| Intelligent Analysis |
|---|
| People Counting Groups | 4 |
| People Counting Rules per Group | 20 |
| Parking Lot Management |
|---|
| Vehicles | 5,000 |
| Vehicle Groups | 8 |
| Parking Lots | 1 |
| Entrances | 6 |
| Exits | 6 |
| Total Entrances and Exits | 6 |
| Entrance/Exit Points | 6 |
| Access Control |
|---|
| Persons for Door Access Rules | 5,000 (1 password, 2 face images, 3 fingerprints, and 5 cards for each person) |
| Zones | 256 |
| Door Access Rules | 50 |
| Public Passwords | 1,500 |
| Visitor |
|---|
| Appointments Set and in Progress | 10,000 |
| Notification Center |
|---|
| Notification Center Messages | 1,000 |
| Data Storage |
|---|
| Event Records | 2,000,000 |
| Face Recognition Records | 2,000,000 |
| ANPR Records | 2,000,000 |
| Metadata Records | 2,000,000 |
| Access Records | 2,000,000 |
| Video Intercom Records | 2,000,000 |
| Historical Count Records | 2,000,000 |
| In Area Statistical Records | 2,000,000 |
| Heat Map Records | 2,000,000 |
| Visitor Records | 2,000,000 |
| Entrance Records | 2,000,000 |
| Exit Records | 2,000,000 |
| People Entering and Exit Records | 2,000,000 |
| Forced Exit Records | 2,000,000 |
| Operator Logs | 2,000,000 |
| Service Logs | 2,000,000 |
| Server Specification (Single Server) |
|---|
| Total Devices | 1,000 devices |
| Auto-registered Devices | 1,000 devices |
| Video Devices and Channels | 256 devices; 256 channels |
| P2P Devices | 32 devices |
| Add Devices by ONVIF | 256 devices; 256 channels |
| Face Recognition Devices and Channels | 8 devices; 32 channels |
| ANPR Channels | 32 channels |
| Video Metadata Channels | 32 channels |
| Access Control Devices | 64 devices; 64 doors |
| Video Intercom Devices | 1,000 devices |
| Alarm Devices | 16 devices; 160 zones |
| People Counting Channels | 16 channels |
| Heat Map Channels | 16 channels |
| Total Incoming Bandwidth | 350 Mbps |
| Incoming Video Bandwidth | 350 Mbps |
| Incoming Picture Bandwidth | 50 Mbps |
| Total Outgoing Bandwidth | 350 Mbps |
| Outgoing Video Bandwidth | 350 Mbps |
| Outgoing Picture Bandwidth | 50 Mbps |
| Total Storage Bandwidth | 350 Mbps |
| Video Storage Bandwidth | 350 Mbps |
| Picture Storage Bandwidth | 50 Mbps |
| Prerecording Bandwidth for Alarm Recordings | 150 Mbps |
| Maximum Capacity of Central Storage (Local) | 2 TB |
| Maximum Capacity of Central Storage (IPSAN) | 100 TB |
| Storage of Events or Alarms without Pictures | 60 per second |
| Combined Events | 20 per second |
| Access Control Events | 60 per second |
| DSS Mobile Client |
|---|
| Item | iOS | Android |
|---|
| Model | iPhone 5S or later | – | | RAM | – | 2 GB and above | | Resolution | – | 1280 × 720 or higher | | Operating System | iOS 10.0 or later | Android 8.0 or later |
|
| Language | Arabic, English (United States), French, Russian, Simplified Chinese |
