Stock Code: TPC-AEBF5201-T
| Thermal | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Detector Type | Vanadium oxide uncooled focal plane detector | |||||||||
| Effective Pixels | 256 (H) × 192 (V) | |||||||||
| Pixel Pitch | 12 µm | |||||||||
| Spectral Range | 8 µm–14 µm | |||||||||
| Sensitivity (NETD) | ≤35 mK (@f/1.0) | |||||||||
| Focal Length | 3.5 mm; 7 mm | |||||||||
| Field of View | 3.5 mm: H: 50.6°; V: 37.8° 7 mm: H: 24°; V: 18° |
|||||||||
| Thermal Focus Control | F1.0 | |||||||||
| Detection Distance① | 3.5 mm: Vehicle: 400 m (1,312.34 ft); Human: 150 m (492.13 ft) 7 mm: Vehicle: 789 m (2,588.58 ft); Human: 295 m (967.85 ft) |
|||||||||
| Recognition Distance② | 3.5 mm: Vehicle: 100 m (328.08 ft); Human: 38 m (124.67 ft) 7 mm: Vehicle: 498 m (1,633.86 ft); Human: 38 m (124.67 ft) |
|||||||||
| Identification Distance③ | 3.5 mm: Vehicle: 50 m (164.04 ft); Human: 19 m (62.34 ft) 7 mm: Vehicle: 197 m (646.33 ft); Human: 76 m (249.34 ft) |
|||||||||
| Digital Detail Enhancement (DDE) | Yes | |||||||||
| Thermal AGC | Auto / Manual | |||||||||
| Thermal Noise Reduction | 2D NR / 3D NR | |||||||||
| Image Flip | 180°; Mirror | |||||||||
| Color Palettes | 18 (white hot, black hot, fusion, rainbow, golden autumn, midday, iron red, amber, jade, sunset, icefire, painting, pomegranate, emerald, spring, summer, autumn, winter) | |||||||||
| Temperature Measurement Range | Low temperature mode: –20 °C (–4 °F) to +150 °C (+302 °F) High temperature mode: +100 °C (+212 °F) to +550 °C (+1022 °F) Auto mode |
|||||||||
| Temperature Measurement Accuracy | Max. (±2 °C, ±2%) Operating temperature: –20 °C (–4 °F) to +50 °C (+122 °F) |
|||||||||
| Temperature Measurement Mode | Spot: 12 Line: 12 Area: 12 Support 12 rules simultaneously |
|||||||||
| Audio and Video | ||||||||||
| Video Compression | H.264 (High, Main); M-JPEG; H.265 | |||||||||
| Resolution | Main stream: 1280 × 960; 1024 × 768; 640 × 480; 256 × 192; 1280 × 960 (default) Sub stream: 640 × 480; 256 × 192; 256 × 192 (default) |
|||||||||
| Video Frame Rate | Thermal: 50 Hz: (main stream) 1 fps–25 fps adjustable, 25 fps by default; (sub stream) 1 fps–25 fps adjustable, 15 fps by default 60 Hz: (main stream) 1 fps–30 fps adjustable, 30 fps by default; (sub stream) 1 fps–30 fps adjustable, 15 fps by default |
|||||||||
| Image Encoding Format | JPEG | |||||||||
| Function | ||||||||||
| Network Protocol | IPv4/IPv6; HTTP; HTTPS; 802.1x; QoS; FTP; SMTP; UPnP; SNMP; DNS; DDNS; NTP; RTSP; RTP; TCP; UDP; IGMP; ICMP; DHCP; PPPoE | |||||||||
| Region of Interest (RoI) | Yes (customizable) | |||||||||
| Storage | FTP; Micro SD card (256 GB, hot swapping) | |||||||||
| Interoperability | ONVIF; CGI | |||||||||
| Browser | IE: IE8 and later, and explorer with IE core Google: 42 and earlier Firefox: 42 and earlier |
|||||||||
| User/Host | Up to 6 (total bandwidth: 64 MB) | |||||||||
| Security | Authorized username and password; attached MAC address; encrypted HTTPS; IEEE 802.1x; controlled network access | |||||||||
| User Management | Up to 20 users; supports multi-level user permissions (2 levels): management group and user group | |||||||||
| Malfunction Detection | Network disconnection detection; IP conflict detection; memory card state detection; memory space detection | |||||||||
| Micro SD Card (Max.) | 256 GB | |||||||||
| Intelligence | ||||||||||
| Heat Detection | Yes | |||||||||
| Cold/Hot Spot Trace | Yes | |||||||||
| Port | ||||||||||
| Network Port | 1 × RJ-45 (10/100 Base-T) | |||||||||
| Alarm Input | 2 | |||||||||
| Alarm Output | 1 | |||||||||
| Power | ||||||||||
| Power Supply | 12 VDC, PoE (802.3af) | |||||||||
| Power Consumption | <3 W | |||||||||
| ePoE | Yes | |||||||||
| Environment | ||||||||||
| Operating Temperature | –40 °C to +60 °C (–40 °F to +140 °F) | |||||||||
| Operating Humidity | ≤95% | |||||||||
| Physical Characteristics | ||||||||||
| Protection | IP68 | |||||||||
| Reliability | Surge protection: 6 kV Air discharge: 15 kV Contact discharge: 8 kV |
|||||||||
| Structure | ||||||||||
| Product Dimensions | 176.1 mm × 114.7 mm × 96 mm (6.93" × 4.52" × 3.78") (L × W × H) | |||||||||
| Packaging Dimensions | 257 mm × 188 mm × 187 mm (10.12" × 7.4" × 7.36") (L × W × H) | |||||||||
| Net Weight | ≤2 kg (4.41 lb) | |||||||||
| Gross Weight | ≤2.5 kg (5.51 lb) | |||||||||
| Certification | ||||||||||
| Certifications | CE / FCC | |||||||||
| Explosion-proof certification | ATEX, IECEx: II 2G Ex db IIC T6 Gb / II 2D Ex tb IIIC T80 °C Db |
|||||||||
| Temperature Measurement Distance | ||||||||||
| Distance Table |
|
|||||||||
