Adds a 6-pole female XLR inlet to a panel.
This D type flanged chassis connector carries a six pole female XLR link onto an equipment panel. A nickel plated diecast zinc alloy shell and machined silver contacts take the load of broadcast and stage work.
6Pin Count
FemalePlug Type
7.5 ACurrent carrying capacity
SilverContact plating
IP40Protection Grade
-25°C ~ +75°COperating Temperature
Key features
Six pole linkOne shell carries six separate lines and gathers multi channel signal paths at a single point.
Machined contactsSilver plated machined contacts hold the connection through 1000 mating cycles.
Nickel plated metal shellThe diecast zinc alloy shell resists impact and wear.
Solder bucket terminationIt accepts wire up to 18 AWG.
Electrical enduranceA 1400 V test voltage and 3 mΩ typical contact resistance keep signal loss low.
The 133 V service voltage is not suitable for domestic applications above 50 V.
