Carries 75 W to speed dome cameras over a single cable.
An injector that steps in to add high-power supply to a network without PoE. It passes data through while adding Hi-PoE power onto the same cable, running speed dome cameras with high power consumption.
75 WHi-PoE power output
10/100/1000 Base-TLink Speed
802.3af, 802.3at and Hi-PoEPower standard
-30°C ~ 65°COperating Temperature
250 gWeight
210 mm × 75 mm × 38.5 mmDimensions
Hi-PoE 75 W outputPowers speed dome cameras with high power consumption over a single cable.
Gigabit data pass-throughThe two 10/100/1000 Base-T ports move data without dropping speed, and the supply follows the 802.3af, 802.3at and Hi-PoE standards.
PoE extender compatibilityWorks with the PFT1300 PoE extender, reaches up to 300 meters in a two-level cascade and powers up to three IP cameras.
Lightning protection and efficiencyLightning protection sits at Level 4, and the device meets the DoE Level VI efficiency requirement.
Wide temperature rangeOperates between -30°C ~ 65°C and at 10% ~ 90% relative humidity.
PoE pin assignmentPower leaves as positive on pins 1, 2, 4 and 5, and as negative on pins 3, 6, 7 and 8.
