Stock Code: SDR-240-48
| General | |
|---|---|
| Series | SDR |
| Brand | Mean Well |
| Type | Switching Mode |
| Phase | Single Phase |
| Number of Outputs | 1 |
| Input | |
| Input Voltage Range | 88 ~ 264 V AC / 124 ~ 370 V DC |
| Frequency Range | 47 ~ 63 Hz |
| Power Factor (PFC, typ.) | 0.94 / 230 V AC at full load |
| Efficiency (typ.) | 94% |
| Leakage Current | < 1 mA / 240 V AC |
| Output | |
| DC Output Voltage | 48 V DC |
| Rated Current | 5 A |
| Current Range | 0 ~ 5 A |
| Rated Power | 240 W |
| Peak Current | 7.5 A |
| Ripple & Noise (max.) | 50 mVp-p |
| Voltage Adj. Range | 48 ~ 55 V |
| Voltage Tolerance | ±1.0% |
| Line Regulation | ±0.5% |
| Load Regulation | ±1.0% |
| Protection | |
| Overload Protection | 110 ~ 150% of rated output power, auto-recovery |
| Over Voltage Protection | 56 ~ 65 V |
| Over Temperature Protection | Shut down o/p voltage, recovers automatically after temperature goes down |
| Short Circuit Protection | Yes |
| Environment | |
| Working Temperature | -25 ~ +70°C |
| Working Humidity | 20 ~ 95% RH (non-condensing) |
| Storage Temp. / Humidity | -40 ~ +85°C, 10 ~ 95% RH |
| Cooling | Free air convection |
| Safety & EMC | |
| Safety Standards | UL508, TUV BS EN/EN62368-1, AS/NZS 62368.1, BSMI CNS15598-1, EAC TP TC 004 |
| Withstand Voltage | I/P-O/P: 3 kV AC; I/P-FG: 2 kV AC; O/P-FG: 0.5 kV AC |
| Isolation Resistance | > 100 MΩ / 500 V DC |
| EMC Emission | BS EN/EN55032 (CISPR32), BS EN/EN61204-3 Class B, BS EN/EN61000-3-2,-3 |
| EMC Immunity | BS EN/EN61000-4-2,3,4,5,6,8,11, heavy industry level, SEMI F47 |
| MTBF | 169.3K hours (MIL-HDBK-217F) |
| Mechanical | |
| Dimensions (W×H×D) | 63 × 125.2 × 113.5 mm |
| Weight | 1.03 kg |
| Mounting | DIN rail TS-35/7.5 or TS-35/15 |
