Stock Code: POE-5616G
| General | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Model | POE5616G | ||||||||
| Power Specifications | |||||||||
| Output Voltage | 48 ~ 56 VDC | ||||||||
| Typical Voltage | 56 VDC | ||||||||
| Maximum Output Current | 1.6 A | ||||||||
| Rated Power | 90 Watt | ||||||||
| Input Voltage | 100 ~ 240 VAC ±10% / 47 ~ 63 Hz | ||||||||
| Inrush Current (Typical) | 20 A max. (cold start at 25 °C, 230 VAC input) | ||||||||
| Input Connector | IEC320-C8 inlet (2 pin) or IEC320-C14 inlet (3 pin) | ||||||||
| LED Indicators | Input power (green), Port (green) | ||||||||
| Number of Ports | 16 | ||||||||
| Data Interfaces | |||||||||
| Data LAN | RJ-45 input | ||||||||
| Cable | EIA/TIA-568 100 ohm (100 m)
| ||||||||
| Standard | Cable Type | ||||||||
| 100BT | 2 pairs UTP/STP Cat.3, 4, 5 | ||||||||
| 100TX | 2 or 4 pairs UTP/STP Cat.5 | ||||||||
| 1000T | 4 pairs UTP/STP Cat.5 | ||||||||
| Data & Power Output | Power feeding pins: 1/2−, 3/6+, 4/5+, 7/8− Data pins: Full duplex | ||||||||
| Protection | |||||||||
| Short Circuit | Recovers automatically once the fault condition is removed | ||||||||
| Overload | Limited at 145% ~ 160% above peak value | ||||||||
| Over Temperature | Output voltage shuts down; operates again once power is re-applied | ||||||||
| Environmental Conditions | |||||||||
| Operating Temperature | −20 °C ~ +60 °C (−4 °F ~ 140 °F) | ||||||||
| Operating Humidity | 10% ~ 90% RH (non-condensing) | ||||||||
| Storage Temperature | −40 °C ~ +70 °C (−40 °F ~ 158 °F) | ||||||||
| Storage Humidity | 8% ~ 90% RH | ||||||||
| Safety & EMC (Electromagnetic Compatibility) | |||||||||
| Safety Standards | CE, LVD, EN60950 | ||||||||
| Withstand Voltage | I/P–O/P: 3.0 KVAC | I/P–GND: 3.0 KVAC | ||||||||
| EMC / EMI Compliance | EN55022, EN55024, FCC Part 15 Subpart B Class B | ||||||||
| RoHS Compliance | Yes | ||||||||
| MTBF (Mean Time Between Failures) | 50,000 hours | ||||||||
| Note | |||||||||
| Power input and output are optional. Default pins are 4/5+, 7/8−; please specify when ordering. All parameters not specially mentioned are measured at 220 VAC input, rated load and 25 °C ambient temperature. | |||||||||
